1FK7032-2AK71-1QG1 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New
$1,115.73
The SIEMENS 1FK7032-2AK71-1QG1 SIMOTICS S synchronous motor delivers compact design, precise performance, and versatile applications in industrial automation.
1FK7032-2AK71-1QG1 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New
The SIEMENS 1FK7032-2AK71-1QG1 belongs to the renowned SIMOTICS S-1FK7 series of permanent-magnet synchronous motors. This compact model is engineered with advanced technology to deliver reliable performance, high efficiency, and superior adaptability in diverse industrial environments. With a rated power of 0.5 kW, a torque of 1.15 Nm at 100K, and a rated speed of 6000 rpm, it ensures smooth and precise operation. The motor features natural cooling, IMB 5 design with flexible mounting options, a flange-mounted connector that can be rotated, and an absolute single-turn 20-bit encoder with DRIVE-CLiQ interface. Its smooth shaft design, IP65 protection class, and tolerance grade N provide long-term durability for continuous use.
The SIMOTICS S-1FK7 family is widely recognized for offering versatile solutions to meet the increasing demands of modern machine design. By combining this motor with the SINAMICS S120 or S220 drive systems, users can benefit from a highly functional and robust drive package. The integrated encoder enhances speed and position control, ensuring precise movement in applications that require high accuracy. Heat is efficiently dissipated through the motor surface, eliminating the need for external cooling systems, while maintaining overload capability for demanding cycles.
Overview
SIMOTICS S-1FK7 motors are compact synchronous motors designed to meet the requirements of modern automation. They can be equipped with multiple encoder options and integrated with various gear units. Their design makes them suitable for universal applications, ranging from simple axes to dynamic, high-performance systems. They offer outstanding energy efficiency, simple commissioning, and minimal maintenance needs.
Benefits
- Space-saving installation thanks to high power density
- Available in compact, high dynamic, and high inertia designs
- Excellent closed-loop control with minimal optimization effort
- Wide application versatility across multiple industries
Applications
- Machine tools and robotics
- Wood, glass, ceramics, and stone processing
- Packaging, plastics, and textile production
- Printing machinery and auxiliary drive systems
Download
Product Code: 1FK7032-2AK71-1QG1
More Siemens products at Turll.com
| Weight | 2.701 kg |
|---|
