1FK7032-2AK71-1RA1 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New
$1,494.02
The SIEMENS 1FK7032-2AK71-1RA1 SIMOTICS S synchronous motor delivers 0.5 kW output, 1.15 Nm torque, and 6000 rpm speed in a compact IP65-protected design, ideal for automation and precision machinery.
1FK7032-2AK71-1RA1 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New
The SIEMENS 1FK7032-2AK71-1RA1 SIMOTICS S synchronous motor is a premium compact drive solution engineered for precision, reliability, and efficiency in demanding industrial applications. With a rated power of 0.5 kW at 600V DC, continuous torque of 1.15 Nm at 100K, and a maximum speed of 6000 rpm, this motor offers outstanding performance while maintaining a naturally cooled design. The flange-mounted configuration with IMB 5 construction allows flexible installation, while the rotatable power connector provides additional convenience during integration. Featuring an absolute encoder with DRIVE-CLiQ interface, the motor ensures accurate speed and position feedback for advanced control systems.
Designed to meet the needs of modern automation, the SIMOTICS S-1FK7 motor series delivers space-saving construction combined with high torque density, making it ideal for compact machine layouts. The rugged housing with IP65 protection safeguards the motor in challenging industrial environments, ensuring durability and long service life even under continuous operation. Without the need for external cooling systems, heat is efficiently dissipated through the surface, further reducing complexity and maintenance requirements.
Overview
The SIMOTICS S-1FK7 motors are highly versatile, available in multiple variants including Compact, High Dynamic, and High Inertia. This flexibility allows users to select the right configuration for specific machine requirements. Compact versions are optimized for universal applications, while High Dynamic models feature very low rotor inertia for fast response. High Inertia motors provide stable closed-loop control under varying loads, ensuring robust performance in challenging conditions.
Benefits
- Space-efficient installation due to compact design and high power density
- Suitable for diverse applications, from machine tools to robotics
- Wide range of models available to meet specific demands
- Fast dynamic response in High Dynamic versions
- Reliable stability in High Inertia variants
- Reduced setup time with minimal tuning required
Applications
- Machine tools and precision cutting equipment
- Robotics and automated handling systems
- Wood, glass, ceramics, and stone processing machinery
- Packaging, plastics, and textile production lines
- Printing and finishing machines
- Auxiliary axes in complex automation systems
Download
Product Code: 1FK7032-2AK71-1RA1
More Siemens products at Turll.com
| Weight | 2.701 kg |
|---|
