1FK7032-2AK71-1RH1-ZJ05 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New

1FK7032-2AK71-1RH1-ZJ05 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New

The SIEMENS 1FK7032-2AK71-1RH1-ZJ05 SIMOTICS S synchronous motor is a premium drive solution designed for demanding industrial applications. With a rated power of 0.5 kW, a rated torque of 1.15 Nm, and a maximum speed of 6000 rpm, this high-precision motor provides exceptional performance in compact form.

It features natural cooling, IMB 5 design (IM V1, IM V3), a rotatable power connector, and an advanced absolute encoder system with DRIVE-CLiQ interface for reliable speed and position feedback. The unit includes a smooth shaft with tolerance class N, an integrated holding brake, and an IP65 protection rating for durability even in challenging environments. Additionally, this model is equipped with an ALPHA SP+ planetary gearbox (SP 060S-MF1, single stage, ratio 1:7) with a feather key, offering robust torque transmission and long-lasting efficiency.

Overview

The SIMOTICS S-1FK7 motor series is a versatile line of permanent-magnet synchronous motors engineered for precision, efficiency, and adaptability. Thanks to its compact design and wide selection of variants, the 1FK7 family can be configured to meet the diverse requirements of modern machines. Combined with SINAMICS S120 or S220 drive systems, these motors form a powerful automation solution with advanced functionality, seamless integration, and high reliability.

Benefits

• Compact installation with high power density
• Available in Compact, High Dynamic, and High Inertia versions
• Flexible encoders and gearboxes for customized performance
• Robust control and reduced commissioning effort
• Natural cooling concept for maintenance-friendly operation

Applications

• Machine tools and robotics
• Handling and automation systems
• Wood, glass, ceramics, and stone processing
• Packaging, plastics, and textile machinery
• Printing and auxiliary axes

Download

Data Sheet (PDF)

Product Code: 1FK7032-2AK71-1RH1-ZJ05
