1FK7033-4CF21-1CH1 SIEMENS Exclusive SIMOTICS S-1FK7 HD Synchronous Motor Original Brand New
$2,028.90
The SIEMENS 1FK7033-4CF21-1CH1 SIMOTICS S-1FK7 HD synchronous motor delivers precise, compact, and high-performance operation with integrated multi-turn encoder feedback, holding brake, and IP65 protection for demanding automation systems.
1FK7033-4CF21-1CH1 SIEMENS Exclusive SIMOTICS S-1FK7 HD Synchronous Motor Original Brand New
The SIEMENS 1FK7033-4CF21-1CH1 SIMOTICS S-1FK7 HD synchronous motor is a compact, high-performance motor engineered for modern industrial automation applications. With a rated power of 0.38 kW and a nominal torque of 1.3 Nm at 3000 rpm, this motor delivers precise motion control with exceptional efficiency. Designed for naturally cooled operation, its heat is dissipated through the motor surface, allowing for stable performance even in demanding environments. The motor features an IMB 5 frame, a rotatable power connector, and a plain shaft with tolerance N, making installation flexible and convenient.
Equipped with a 24-bit absolute encoder and a 12-bit multi-turn system via the DRIVE-CLiQ interface (encoder AM24DQI), the 1FK7033-4CF21-1CH1 ensures accurate position and speed feedback. Its holding brake enhances operational safety and reliability, while the IP65-rated design protects the motor from dust and water ingress, ensuring long-term durability in harsh industrial conditions. This motor is ideal for use with SINAMICS S120 and S220 drive systems to form a powerful, fully integrated motion control solution.
Overview
SIMOTICS S-1FK7 motors are permanent-magnet synchronous motors designed for compact, high-efficiency operation. A variety of gearboxes, encoder options, and product variants allow these motors to meet a wide range of application requirements. High-dynamic versions deliver rapid response for precision control, while high-inertia models provide robust closed-loop performance under variable load conditions. Installation is simplified due to the motor’s high power density and adaptable configuration.
Benefits & Applications
- Compact design for space-saving installations
- Universal application across multiple industries
- High overload capability and reliable performance
- Machine tools, robots, and handling systems
- Wood, glass, ceramics, and stone working
- Packaging, plastics, and textile machinery
- Printing machines and auxiliary axes
Download
Product Code: 1FK7033-4CF21-1CH1
More Siemens products at Turll.com
| Weight | 3.3 kg |
|---|
