1FK7033-4CK71-1RH1 SIEMENS Exclusive SIMOTICS S-1FK7-HD Synchronous Motor Original Brand New

1FK7033-4CK71-1RH1 SIEMENS Exclusive SIMOTICS S-1FK7-HD Synchronous Motor Original Brand New

The SIEMENS 1FK7033-4CK71-1RH1 SIMOTICS S-1FK7-HD synchronous motor is engineered for high-performance industrial applications that require precision, reliability, and efficiency. Delivering 0.57 kW nominal power with a torque of 1.3 Nm at 6000 rpm, this motor combines compact dimensions with exceptional output. Its naturally cooled IMB 5 design allows operation without additional cooling systems, while heat is dissipated effectively through the motor housing, ensuring continuous operation even under demanding conditions.

This model features a 20-bit absolute encoder plus a 12-bit multi-turn encoder with DRIVE-CLiQ interface, enabling accurate position and speed feedback. The plain shaft with tolerance N and integrated holding brake enhances operational flexibility and safety. The rotatable power connector simplifies installation, while the IP65-rated enclosure protects against dust and water ingress, making it suitable for diverse industrial environments.

Overview

SIMOTICS S-1FK7 motors are compact permanent-magnet synchronous motors designed for modern automation systems. With a wide selection of optional gearboxes and encoders, they can be customized for specific applications. These motors support integration with SINAMICS S120/S220 drive systems, offering a robust solution for speed and position control. High-dynamic variants provide rapid response due to low rotor inertia, while high-inertia versions offer stable performance under variable load conditions.

Benefits & Applications

• High power density allowing space-saving installations
• Versatile for multiple industrial applications
• Minimal commissioning effort with reduced optimization needs
• Ideal for machine tools, robotic and handling systems
• Suitable for woodworking, glass, ceramics, stone, plastics, textiles, and printing machinery
• Supports auxiliary axes in advanced automation setups

Download

Data Sheet (PDF)

Product Code: 1FK7033-4CK71-1RH1
