1FK7034-2AF21-1BH0 SIEMENS Exclusive SIMOTICS S-1FK7 Synchronous Motor Original Brand New

1FK7034-2AF21-1BH0 SIEMENS Exclusive SIMOTICS S-1FK7 Synchronous Motor Original Brand New

The SIEMENS 1FK7034-2AF21-1BH0 SIMOTICS S-1FK7 synchronous motor is a compact, high-efficiency solution developed to deliver precise motion control for industrial automation systems. With a rated power of 0.47 kW and a nominal torque of 1.6 Nm at 3000 rpm, it provides dependable performance in demanding applications. The motor operates under a 300 V DC link voltage and features a naturally cooled IMB 5 design for enhanced thermal management without external fans, ensuring continuous, stable operation across varied industrial environments.

Engineered with a 24-bit single-turn absolute encoder using the DRIVE-CLiQ interface (AS24DQI), this motor ensures exceptional feedback precision and synchronization accuracy. The smooth shaft design with tolerance N, integrated holding brake, and rotatable power connector allow flexible installation, reducing downtime during setup and maintenance. With IP64 protection, the unit is resistant to dust and water spray, making it ideal for robust, long-term use in production lines and automated systems.

Overview

SIMOTICS S-1FK7 motors are compact permanent-magnet synchronous motors built for performance and flexibility. Their modular structure allows pairing with SINAMICS S120 or S220 drive systems to achieve superior motion control. Offering multiple motor types, these units meet diverse industrial requirements from compact to high dynamic or high inertia models. This adaptability makes them suitable for high-precision machinery and intelligent automation setups.

Benefits & Applications

• Compact installation with high torque density
• Reliable closed-loop control for precision positioning
• Wide compatibility with SINAMICS drive systems
• Reduced commissioning time with preconfigured encoder interface
• Ideal for machine tools, robotic arms, and material handling
• Applicable in packaging, printing, plastics, textile, and woodworking industries

Download

Data Sheet (PDF)

Product Code: 1FK7034-2AF21-1BH0
