1FK7034-2AF21-1QB0 SIEMENS Exclusive SIMOTICS S-1FK7 Synchronous Motor Original Brand New

1FK7034-2AF21-1QB0 SIEMENS Exclusive SIMOTICS S-1FK7 Synchronous Motor Original Brand New

The SIEMENS 1FK7034-2AF21-1QB0 SIMOTICS S-1FK7 synchronous motor is a high-performance compact motor designed to deliver outstanding efficiency and precision for modern industrial automation. Built with a naturally cooled design and IMB 5 mounting configuration, this motor achieves reliable performance across a wide range of applications. With a nominal power of 0.47 kW, rated torque of 1.6 Nm, and speed of 3000 rpm, it provides an exceptional balance between performance and energy efficiency.

This exclusive synchronous motor integrates an absolute single-turn 20-bit encoder with a DRIVE-CLiQ interface, ensuring precise feedback for accurate speed and position control. The rotatable power connector enhances installation flexibility, while the shaft with feather key and holding brake offer superior mechanical safety and stability. Engineered to an IP64 degree of protection, the motor is well-suited for demanding environments that require durability, reliability, and long service life.

Overview

SIMOTICS S-1FK7 motors are compact permanent-magnet synchronous motors that stand out for their adaptability and advanced performance characteristics. Their modular concept allows easy configuration with a range of encoders, gearboxes, and drive systems. When combined with the SINAMICS S120 or S220 drive platforms, these motors form a powerful motion control system with high functionality and efficiency.

Benefits & Applications

• Space-saving installation with high power density
• Consistent torque and speed across diverse applications
• Excellent dynamic response with minimal inertia
• Low maintenance and high mechanical integrity
• Ideal for machine tools, robotics, and handling systems
• Suitable for packaging, plastics, textile, and printing machinery
• Effective for woodworking, ceramics, and auxiliary axes

Download

Data Sheet (PDF)

Product Code: 1FK7034-2AF21-1QB0
