1FK7034-2AK71-1CG1-ZJ09 SIEMENS Exclusive SIMOTICS S-1FK7 Synchronous Motor Original Brand New

1FK7034-2AK71-1CG1-ZJ09 SIEMENS Exclusive SIMOTICS S-1FK7 Synchronous Motor Original Brand New

The SIEMENS 1FK7034-2AK71-1CG1-ZJ09 SIMOTICS S-1FK7 synchronous motor is a premium-grade solution designed for high-precision and high-efficiency industrial automation systems. Delivering 0.63 kW of power with a nominal torque of 1.6 Nm and a rated speed of 6000 rpm, this compact motor offers exceptional performance in a naturally cooled IMB 5 configuration. Its design enables optimal heat dissipation through the motor’s surface, ensuring consistent operation even under demanding workloads.

Equipped with a 24-bit absolute encoder and 12-bit multi-turn system using the DRIVE-CLiQ interface (encoder AM24DQI), the 1FK7034-2AK71-1CG1-ZJ09 provides precise position and speed control, ideal for integration with SINAMICS S120 or S220 drive systems. The smooth shaft with tolerance N, rotatable power connector, and IP65 protection make this motor a reliable choice for various industrial applications. The integrated ALPHA SP+ SP 060S-MF1 planetary gearing (1 stage, ratio 10) with feather key provides optimized torque transmission, improving mechanical performance and energy efficiency.

Overview

SIMOTICS S-1FK7 motors are high-performance permanent-magnet synchronous motors tailored for modern automation tasks. Their compact design, flexible configuration options, and compatibility with advanced drive systems allow seamless customization across industries. They are capable of delivering dynamic motion, high torque density, and robust overload capacity, making them a trusted solution for precision-controlled machinery.

Benefits & Applications

• Compact design ensuring space-saving installation
• High torque accuracy and low maintenance requirements
• Universal adaptability for multi-axis motion systems
• Integrated planetary gear for efficient power transmission
• Ideal for machine tools, robotics, packaging, and material handling
• Suitable for industries such as plastics, textiles, printing, glass, and ceramics

Download

Data Sheet (PDF)

Product Code: 1FK7034-2AK71-1CG1-ZJ09
