1FK7034-2AK71-1CH0 SIEMENS Exclusive SIMOTICS S-1FK7 Synchronous Motor Original Brand New

1FK7034-2AK71-1CH0 SIEMENS Exclusive SIMOTICS S-1FK7 Synchronous Motor Original Brand New

The SIEMENS 1FK7034-2AK71-1CH0 SIMOTICS S-1FK7 synchronous motor delivers exceptional performance and reliability for modern automation systems. With a nominal power of 0.63 kW and torque of 1.6 Nm at 6000 rpm, this motor is designed for precision-driven applications requiring stable and efficient operation. It utilizes a permanent-magnet rotor and operates with a 600V DC link voltage, offering excellent energy efficiency and consistent torque delivery across variable loads.

Built for compact installations, the motor features a naturally cooled IMB 5 design that effectively dissipates heat through its surface, eliminating the need for external cooling. The absolute encoder provides 24-bit single-turn and 12-bit multi-turn resolution through a Drive-CLiQ interface (encoder AM24DQI), ensuring precise feedback and smooth integration into SINAMICS S120 and S220 drive systems. Its rotatable power connector and smooth shaft design with tolerance class N simplify installation while maintaining superior mechanical alignment.

Overview

SIMOTICS S-1FK7 motors represent a flexible and powerful range of synchronous motors tailored for automation. They combine compact dimensions with robust performance and are available in multiple configurations to match diverse industrial needs. The integrated encoder options allow for both position and speed control, ensuring precise motion and dynamic response. The series also supports applications that demand high torque accuracy and consistent rotational speed.

Benefits & Applications

• Compact structure with high power density for space-saving installations
• Excellent dynamic response with low rotor moment of inertia
• Versatile use in multiple industries including robotics and manufacturing
• High overload capability for demanding operational conditions
• Seamless compatibility with SINAMICS drive systems
• Ideal for machine tools, packaging systems, and automated handling equipment

Download

Data Sheet (PDF)

Product Code: 1FK7034-2AK71-1CH0
