1FK7034-2AK71-1PG1 SIEMENS Exclusive SIMOTICS S-1FK7 Synchronous Motor Original Brand New
$1,109.17
The SIEMENS 1FK7034-2AK71-1PG1 SIMOTICS S-1FK7 synchronous motor provides precise, compact, and high-performance operation for automation systems, featuring integrated 2-pole resolver, IP65 protection, and flexible installation options.
1FK7034-2AK71-1PG1 SIEMENS Exclusive SIMOTICS S-1FK7 Synchronous Motor Original Brand New
The SIEMENS 1FK7034-2AK71-1PG1 SIMOTICS S-1FK7 synchronous motor delivers high-precision performance in a compact, robust design, tailored for demanding industrial automation tasks. With a nominal power rating of 0.63 kW and a torque of 1.6 Nm at 6000 rpm, this motor provides reliable operation for a wide range of machinery. Its naturally cooled IMB 5 design enables operation without additional cooling systems, as heat is efficiently dissipated through the motor surface, ensuring stable performance under continuous loads.
This exclusive motor is equipped with a 2-pole resolver integrated via the DRIVE-CLiQ interface, providing accurate position and speed feedback for advanced automation systems. The smooth shaft with tolerance N allows precise mechanical coupling, while the rotatable power connector simplifies installation and alignment. Designed with IP65 protection, the motor resists dust and water ingress, making it suitable for challenging industrial environments. This variant operates without a holding brake, offering flexibility for specific application requirements.
Overview
SIMOTICS S-1FK7 motors are compact, permanent-magnet synchronous motors suitable for a broad spectrum of automation needs. The motors can be customized with optional gearboxes and encoder systems, allowing integration into SINAMICS S120 or S220 drive systems to achieve a powerful, highly functional solution. The series accommodates both high-dynamic and high-inertia applications, enabling rapid response and robust closed-loop control for variable loads.
Benefits & Applications
- High power density enables space-saving installation in compact machinery
- Universal adaptability across multiple automation sectors
- Low rotor inertia ensures excellent dynamic response for fast movements
- Robust performance for variable load applications with minimal commissioning
- Ideal for machine tools, robotic systems, and handling equipment
- Suitable for woodworking, glass, ceramics, plastics, textiles, and printing machines
- Supports auxiliary axes and precision motion control tasks
Download
Product Code: 1FK7034-2AK71-1PG1
More Siemens products at Turll.com
| Weight | 3.801 kg |
|---|
