1FK7034-2AK71-1RG1-ZJ15 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New

1FK7034-2AK71-1RG1-ZJ15 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New

The SIEMENS 1FK7034-2AK71-1RG1-ZJ15 is a high-quality synchronous motor from the renowned SIMOTICS S-1FK7 series, engineered for precision, durability, and efficiency. With a rated power output of 0.63 kW and a nominal speed of 6000 rpm, this motor is ideal for demanding automation and motion control applications. Its naturally cooled design and IP65 degree of protection make it suitable for use in various industrial environments. The smooth shaft, combined with a 20-bit absolute encoder featuring a 12-bit multi-turn Drive-CLiQ interface (encoder AM20DQI), ensures superior accuracy and responsive feedback for both position and speed control.

Overview

SIMOTICS S-1FK7 motors are compact, permanent-magnet synchronous motors known for their outstanding performance and reliability. Designed to meet modern automation standards, they offer flexible configuration options, including a wide range of gearboxes and encoder variants. When paired with the SINAMICS S120/S220 drive systems, these motors deliver an advanced and versatile motion control solution. Their maintenance-free operation, coupled with high overload capability, ensures long-term efficiency and reduced downtime. The 1FK7 series is optimized for applications requiring both precision and power in compact spaces.

Design and Benefits

The 1FK7034-2AK71-1RG1-ZJ15 features a robust construction in the IMB 5 mounting design, offering reliable mechanical stability and smooth operation. With its ALPHA SP+ SP 075S-MF2 planetary gearbox (two-stage, i=28, with feather key), it provides high torque transmission and mechanical efficiency. The motor’s high power density allows for space-saving installation, while its natural convection cooling supports consistent thermal performance. Compact yet powerful, it guarantees high dynamic response and exceptional control characteristics. This configuration is perfect for precise movement and high-speed operation, essential in modern industrial machinery.

Applications

The SIMOTICS S-1FK7 Compact series is suitable for a wide range of automation applications, including machine tools, robotics, packaging, and textile systems. It is also ideal for use in wood, glass, ceramics, and stone processing machines, as well as printing and auxiliary motion axes. Each motor in this series combines precision engineering with reliability to meet the demands of diverse industrial operations.

Download

Data Sheet (PDF)

Product Code: 1FK7034-2AK71-1RG1-ZJ15
