1FK7034-2AK71-1UH1 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New
$1,287.09
The SIEMENS SIMOTICS S 1FK7034-2AK71-1UH1 synchronous motor delivers outstanding precision, efficiency, and flexibility for high-performance automation systems. Featuring 0.63 kW power, 1.6 Nm torque, and 6000 rpm speed, this compact motor ensures long-term reliability and superior control in a wide range of industrial applications.
1FK7034-2AK71-1UH1 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New
The SIEMENS SIMOTICS S 1FK7034-2AK71-1UH1 is a high-performance synchronous motor engineered for advanced motion control applications. This model features a rated power of 0.63 kW, a torque of 1.6 Nm (100K), and a nominal speed of 6000 rpm. Designed with a naturally cooled structure and a flange-mounted IMB 5 (IM V1, IM V3) configuration, it ensures stable and efficient performance under continuous operation. Equipped with a rotatable multi-pole resolver and a DRIVE-CLiQ interface, it offers precise communication with SIEMENS drive systems for accurate motion feedback and synchronization. The smooth shaft and integrated holding brake provide reliable mechanical control and safety, while the IP65 protection class ensures resistance against dust and water for long-term durability.
Overview
The SIMOTICS S-1FK7 motor series represents SIEMENS’ commitment to compact, high-efficiency servo solutions for modern automation environments. These permanent-magnet synchronous motors combine excellent performance with compact dimensions, making them ideal for space-limited installations. Their broad compatibility with SINAMICS S120 and S220 drive systems allows for powerful, flexible, and intelligent drive configurations. Integrated encoder systems enable precise position and speed control, ensuring optimized system response and stability across various industrial applications. With surface-based heat dissipation and robust overload capacity, these motors maintain reliability even in challenging conditions.
Benefits
The SIMOTICS S-1FK7 Compact motors are designed for space-saving installations, delivering exceptional power density and versatility for universal applications. The High Dynamic versions offer superior response times thanks to their lightweight rotor design, while the High Inertia variants provide steady control for applications with high or fluctuating load moments. Each version supports reduced commissioning effort and seamless system integration, improving both performance and efficiency.
Application
Ideal for precision-driven industries, the 1FK7034-2AK71-1UH1 motor is widely used in machine tools, robotics, packaging systems, and material-handling equipment. It also excels in wood, glass, ceramics, stone, and textile processing, as well as printing and auxiliary axis applications where consistent torque and responsiveness are essential.
Download
Product Code: 1FK7034-2AK71-1UH1
More Siemens products at Turll.com
| Weight | 4.001 kg |
|---|
