1FK7040-2AK71-1CA0 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New

1FK7040-2AK71-1CA0 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New

The SIEMENS SIMOTICS S 1FK7-CT synchronous motor (Product Code: 1FK7040-2AK71-1CA0) is a compact, high-performance permanent-magnet motor designed for precision industrial applications. Delivering 0.69 kW power with a rated speed of 6000 rpm, this motor combines efficiency, reliability, and advanced technology in a space-saving design. It features a 24-bit +12 bit multi-turn absolute encoder with DRIVE-CLiQ interface (AM24DQI), naturally cooled surface for optimal heat dissipation, and a rotatable power connector, providing flexibility for varied installation environments. Its shaft includes a feather key with N tolerance, offering secure mechanical integration, and it is rated IP64 for protection against dust and water ingress.

Overview

The SIMOTICS S‑1FK7 series is engineered to deliver high power density and precise control for modern machine tools, robots, and automation systems. The motors are compatible with the SINAMICS S120/S220 drive systems, enabling seamless integration for complete motion solutions. The integrated encoder systems allow accurate speed and position monitoring, which can be selected depending on the application requirements. Thanks to the naturally cooled design, external cooling is unnecessary, reducing maintenance needs and optimizing installation space.

Benefits

• Space-saving installation due to high power density.
• Versatile usage across a wide range of industrial applications.
• High dynamic response in High Dynamic variants thanks to minimal rotor inertia.
• Robust control properties for High Inertia variants, capable of handling variable load moments.
• Minimal setup and commissioning overhead with advanced encoder integration.

Applications

• Machine tools, auxiliary axes, and handling systems.
• Robotics and automated production equipment.
• Processing machines for wood, glass, ceramics, and stone.
• Packaging, plastics, textiles, and printing machinery.

Download

Data Sheet (PDF)

Product Code: 1FK7040-2AK71-1CA0
