1FK7040-2AK71-1CG1-ZJ09 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New

1FK7040-2AK71-1CG1-ZJ09 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New

The SIEMENS SIMOTICS S 1FK7040-2AK71-1CG1-ZJ09 is a premium-grade synchronous motor engineered for precise motion control and energy-efficient performance in modern industrial automation. This model delivers 0.69 kW power output at a rated speed of 6000 rpm, providing exceptional torque density and long-term reliability. Featuring a smooth shaft and an integrated 24-bit absolute encoder with DRIVE-CLiQ interface, this motor ensures outstanding position accuracy and synchronization across applications. Its naturally cooled construction, IP65 protection, and flange-mounted IMB 5 design make it ideal for operation in demanding environments where performance, durability, and precision are essential.

Overview

The SIMOTICS S-1FK7 motor family represents Siemens’ commitment to innovation in servo motion technology. Built as a compact permanent-magnet synchronous motor, it combines superior performance with minimal space requirements. The series offers extensive configuration options, allowing users to select suitable encoders, gearboxes, and mechanical variants for any automation setup. Seamlessly integrated with SINAMICS S120 or S220 drive systems, it forms a powerful and flexible motion control solution that meets the rising demands of next-generation machines. With integrated encoder systems, these motors enable accurate speed and position control without the need for additional cooling, as thermal energy is efficiently dissipated through the motor housing. The result is a highly durable system capable of continuous operation under heavy loads.

Benefits

SIMOTICS S-1FK7 Compact motors provide space-saving installation through exceptionally high power density, making them ideal for universal industrial use. The High Dynamic variants offer rapid acceleration and response times due to their low rotor inertia, while the High Inertia versions deliver robust control for applications with high or fluctuating loads. These motors minimize commissioning effort and simplify system optimization, contributing to stable, efficient, and quiet operation even under demanding conditions.

Application

This synchronous servo motor is suited for a wide range of automation and manufacturing systems. Typical applications include machine tools, industrial robots, packaging and textile machinery, wood and glass processing, as well as printing and auxiliary axes. The integrated ALPHA SP+ SP 075S-MF1 planetary gearing (1 stage, I=10) enhances performance by providing optimized torque transmission with maximum precision.

Download

Data Sheet (PDF)

Product Code: 1FK7040-2AK71-1CG1-ZJ09
