1FK7040-2AK71-1UG2 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New
$1,083.76
The SIEMENS SIMOTICS S 1FK7040-2AK71-1UG2 is a compact synchronous servo motor engineered for high precision and reliable performance. With 0.69 kW power, 6000 rpm speed, and IP65 protection, it delivers efficient motion control for industrial machinery, robotics, and automation systems.
1FK7040-2AK71-1UG2 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New
The SIEMENS SIMOTICS S synchronous motor 1FK7040-2AK71-1UG2 is a high-quality, compact servo motor designed for precision, performance, and long-term reliability in industrial automation. Operating at 0.69 kW with a rated torque of 1.6 Nm (100K) and a nominal speed of 6000 rpm, this motor offers outstanding energy efficiency and precise control. With a 600V DC link voltage, naturally cooled design, and a smooth shaft, the 1FK7040-2AK71-1UG2 ensures superior mechanical stability. It is equipped with a multi-pole resolver and a DRIVE-CLiQ interface for seamless integration with SIEMENS drive systems. The IP65 degree of protection and rotatable power connector make it suitable for demanding environments where durability and flexibility are essential.
Overview
The SIMOTICS S-1FK7 motor series represents the new generation of SIEMENS permanent-magnet synchronous motors, providing exceptional dynamics and compact dimensions. These motors can be combined with SINAMICS S120 or S220 drive systems to form a powerful, modular motion control solution. Designed for maintenance-free operation, they dissipate heat naturally through the motor surface, eliminating the need for external cooling systems. With a wide range of versions, encoder systems, and gearbox options, SIMOTICS S-1FK7 motors can be adapted for almost any industrial automation requirement. The integrated encoders allow precise control of speed and position, ensuring high accuracy and stability even under variable load conditions.
Benefits
- Compact design allows space-saving installation with a high power-to-size ratio.
- Excellent dynamic response due to low rotor inertia.
- Flexible configurations support diverse industrial applications.
- High overload capacity and stable torque characteristics for demanding operations.
- Compatible with SIEMENS SINAMICS drive systems for seamless system integration.
Applications
- Machine tools and robotic systems
- Packaging and textile machinery
- Wood, glass, ceramics, and stone processing
- Printing and material handling systems
- Automation and auxiliary axis control
Download
Product Code: 1FK7040-2AK71-1UG2
More Siemens products at Turll.com
| Weight | 3.202 kg |
|---|
