1FK7042-2AC71-1FG2 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New
$1,985.89
The SIEMENS SIMOTICS S 1FK7042-2AC71-1FG2 is a compact synchronous motor offering 0.59 kW power and 3 Nm torque at 2000 rpm. Designed for high precision and reliability, it features an absolute encoder, IP65 protection, and natural cooling, making it ideal for robotics, packaging, and automation systems.
1FK7042-2AC71-1FG2 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New
The SIEMENS SIMOTICS S 1FK7042-2AC71-1FG2 is a high-quality synchronous motor engineered to deliver precision, reliability, and long-term operational efficiency. With a rated power of 0.59 kW and a torque output of 3 Nm, this motor operates at 2000 rpm under a DC voltage of 600V. Designed with a naturally cooled system and an IP65 degree of protection (IP67 at the flange), it ensures excellent durability and stable performance under challenging industrial conditions. This model features a plain shaft with a rotatable power connector, as well as an integrated absolute encoder AM22DQ offering 22-bit single-turn and 12-bit multi-turn resolution for precise feedback and control.
Overview
The SIMOTICS S-1FK7 series by SIEMENS represents a new generation of compact permanent-magnet synchronous motors, combining outstanding power density with exceptional flexibility. These motors can be seamlessly integrated into advanced drive systems such as SINAMICS S120 or S220, forming a high-performance motion control solution. The product line supports a wide range of configurations, ensuring compatibility with numerous automation environments. Thanks to their integrated encoder systems, these motors provide accurate speed and position control for complex machine applications.
Benefits
The SIMOTICS S-1FK7 Compact series is ideal for space-saving installations where efficiency and precision are critical. Its high power density allows versatile use in robotics, machine tools, and packaging systems. The High Dynamic variants offer rapid response due to minimal rotor inertia, while the High Inertia models provide robust closed-loop control for applications with variable load conditions. This combination of flexibility and reliability makes the SIMOTICS S-1FK7 series a preferred choice for modern automation.
Application
Typical uses include machine tools, robotics, material handling, packaging equipment, and systems used in wood, glass, and textile processing. Each motor is engineered to maintain high performance and minimal maintenance requirements across diverse industrial sectors.
Download
Product Code: 1FK7042-2AC71-1FG2
More Siemens products at Turll.com
| Weight | 4.601 kg |
|---|
