1FK7042-2AF21-1CH1 SIEMENS Exclusive SIMOTICS S-1FK7 Compact Synchronous Motor Original Brand New
$2,134.16
The SIEMENS SIMOTICS S-1FK7 motor (1FK7042-2AF21-1CH1) is a compact synchronous motor delivering 0.82 kW of power at 3000 rpm with high reliability, integrated encoder, holding brake, and IP65 protection for industrial automation applications.
1FK7042-2AF21-1CH1 SIEMENS Exclusive SIMOTICS S-1FK7 Compact Synchronous Motor Original Brand New
The SIEMENS SIMOTICS S-1FK7 motor with part number 1FK7042-2AF21-1CH1 is a highly versatile synchronous motor designed to deliver precise and reliable performance across industrial applications. Rated at 0.82 kW with a nominal voltage of 300 V and a speed of 3000 rpm, this motor features a naturally cooled design and compact flange type IMB 5 (IM V1, IM V3). The power connector is rotatable, and the motor is equipped with a 24-bit absolute encoder plus a 12-bit multi-turn encoder integrated via the DRIVE-CLiQ interface (encoder AM24DQI). The smooth shaft with tolerance N and integrated holding brake provides enhanced operational stability, while the IP65 protection rating ensures suitability for harsh industrial environments.
Overview
The SIMOTICS S-1FK7 series is renowned for compact permanent-magnet synchronous motors optimized for modern machine requirements. These motors can be seamlessly integrated with SINAMICS S120 or S220 drive systems, forming powerful, high-functionality solutions for demanding automation tasks. The integrated encoder systems allow precise speed and position control and can be selected based on specific application needs. With heat dissipation through the motor surface, these motors operate efficiently without external cooling and offer high overload capability, ensuring reliable long-term operation.
Benefits
The compact variants provide space-saving installation and universal applicability, accommodating a wide range of machinery. High Dynamic versions deliver extremely responsive operation due to minimal rotor inertia, while High Inertia motors maintain robust closed-loop control for high or variable load moments. Across all configurations, SIMOTICS S-1FK7 motors minimize optimization and commissioning efforts while compensating for potential disturbances, making them highly adaptable in industrial automation.
Applications
These motors are widely used in machine tools, robotics, and handling systems. They are ideal for woodworking, glass, ceramics, and stone processing machines, as well as in packaging, plastics, and textile equipment. Additional applications include printing machinery and auxiliary axes requiring precise, high-performance drive solutions.
Download
Product Code: 1FK7042-2AF21-1CH1
More Siemens products at Turll.com
| Weight | 4.9 kg |
|---|
