1FK7042-2AF71-1BG0-ZV42 SIEMENS Exclusive SIMOTICS S-1FK7 Synchronous Motor Original Brand New

1FK7042-2AF71-1BG0-ZV42 SIEMENS Exclusive SIMOTICS S-1FK7 Synchronous Motor Original Brand New

The SIEMENS SIMOTICS S-1FK7 motor with part number 1FK7042-2AF71-1BG0-ZV42 is an advanced synchronous servo motor designed for high-precision motion control and outstanding mechanical reliability. With a rated power of 0.82 kW and torque of 3 Nm at 3000 r/min, this motor offers efficient performance and smooth operation across a wide range of industrial applications. Built to support demanding automation environments, it delivers continuous power, stability, and dynamic responsiveness in a naturally cooled, compact housing that supports multiple mounting orientations (IM B5, IM V1, IM V3).

The motor integrates an absolute single-turn 24-bit encoder with a DRIVE-CLiQ interface, providing exceptional feedback accuracy for high-precision position and speed control. Equipped with a plain shaft and planetary gearbox (ALPHA LP+ LP 090-MO1, 1-stage, ratio 10), it ensures optimal torque transmission and mechanical compatibility for diverse automation systems. The IP64 protection rating guarantees resistance to dust and splashing water, making it suitable for challenging industrial settings.

Overview

The SIMOTICS S-1FK7 series represents a new generation of compact permanent-magnet synchronous motors, offering exceptional versatility and adaptability. These motors can be seamlessly paired with SINAMICS S120 or S220 drives to form a complete, high-functionality system. Thanks to integrated encoders and an extensive selection of gear and size options, the S-1FK7 family fits almost any automation requirement, ensuring efficient energy use, low maintenance, and consistent performance.

Design and Applications

Engineered for maintenance-free operation, the S-1FK7 dissipates heat through its outer frame, maintaining high overload capacity without external cooling. Compact dimensions enable space-saving installation, while the optimized rotor design enhances control stability and responsiveness. Typical applications include machine tools, robotic systems, packaging equipment, printing, and various material-processing machines in the wood, glass, ceramics, and textile industries.

Download

Data Sheet (PDF)

Product Code: 1FK7042-2AF71-1BG0-ZV42
