1FK7042-2AF71-1BG2-ZN16X01 SIEMENS Exclusive SIMOTICS S-1FK7 Compact Synchronous Motor Original Brand New

1FK7042-2AF71-1BG2-ZN16X01 SIEMENS Exclusive SIMOTICS S-1FK7 Compact Synchronous Motor Original Brand New

The SIEMENS SIMOTICS S-1FK7 motor with part number 1FK7042-2AF71-1BG2-ZN16X01 represents exceptional performance and reliability for modern automation systems. This synchronous motor features a compact, naturally cooled design with a rated power of 0.82 kW and a rated torque of 3 Nm, operating at 3000 r/min under 600 V DC. Built for industrial durability, it includes an absolute encoder single-turn 24-bit with DRIVE-CLiQ interface for precise speed and position feedback. The plain shaft version with tolerance N and IP65 protection ensures stable operation even under demanding conditions.

Overview

The SIMOTICS S-1FK7 family is known for its compact structure, high power density, and versatility across a wide range of motion control applications. These permanent-magnet synchronous motors are designed for use with the SINAMICS S120/S220 drive systems, creating a high-performance automation solution. Each motor integrates an advanced encoder system for dynamic speed and position control, supporting precise and efficient machine operation. Thanks to its natural cooling method, heat dissipation occurs through the motor housing, eliminating the need for external cooling systems.

Design and Benefits

This model features enhanced chemical resistance and an M17 encoder plug (version N16) with a dull black RAL9005 paint finish (option X01) for superior durability in harsh environments. The design emphasizes long service life, simple integration, and reliable operation in both vertical and horizontal configurations (IMB5/IMV1/IMV3). With a rotatable power connector and robust mechanical construction, it ensures easy installation and maintenance.

Key advantages include space-saving installation, a wide torque range, and strong overload capacity. The SIMOTICS S-1FK7 motor family offers excellent control stability and minimal setup time, making it ideal for high-precision systems requiring fast response and consistent performance.

Applications

The 1FK7042-2AF71-1BG2-ZN16X01 motor is widely used in machine tools, robotic systems, packaging machinery, wood and glass processing, and textile equipment. Its reliability, efficiency, and precise motion control make it a trusted choice for OEMs and system integrators seeking robust, compact motor solutions.

Download

Data Sheet (PDF)

Product Code: 1FK7042-2AF71-1BG2-ZN16X01
