1FK7042-2AF71-1CG1-ZJ29X01 SIEMENS Exclusive SIMOTICS S-1FK7 Synchronous Motor Original Brand New

1FK7042-2AF71-1CG1-ZJ29X01 SIEMENS Exclusive SIMOTICS S-1FK7 Synchronous Motor Original Brand New

The SIEMENS SIMOTICS S-1FK7 motor with the serial number 1FK7042-2AF71-1CG1-ZJ29X01 is a high-performance synchronous servo motor designed for precision, reliability, and efficiency in industrial automation. With a rated power of 0.82 kW and a torque of 3 Nm at 3000 rpm, it provides exceptional motion control in compact form. The motor features natural cooling, a rotatable power connector, and a plain shaft with tolerance N. It integrates an absolute multiturn encoder (AM24DQI) with 24-bit + 12-bit resolution, communicating via the advanced DRIVE-CLiQ interface to ensure accurate positioning and superior feedback performance. Built with an IP65 protection class, this motor withstands demanding environments, offering dependable performance over long operating cycles.

Overview

The SIMOTICS S-1FK7 series represents the next generation of compact permanent-magnet synchronous motors by Siemens. This product line is engineered to provide maximum adaptability through multiple configurations of gear units, encoders, and mounting options. The 1FK7 motors combine high torque density with low inertia, making them suitable for both dynamic and high-precision applications. When paired with SINAMICS S120 or S220 drives, the system delivers powerful motion control with high functionality, smooth acceleration, and precise speed regulation.

These motors are air-cooled and optimized for energy-efficient performance without external cooling systems. The heat generated is dissipated directly through the housing, ensuring consistent operation even under continuous loads. A standout advantage of the SIMOTICS S-1FK7 family is its high overload capacity, providing enhanced reliability and safety in high-demand production lines.

Benefits

• Compact design for space-saving installation and high power density
• Universal applicability across multiple automation platforms
• Exceptional torque and acceleration response with low rotor inertia
• Stable performance with strong closed-loop control characteristics
• Reduced commissioning and optimization efforts
• Available in High Dynamic, Compact, and High Inertia variants

Applications

• Machine tools and precision robots
• Packaging, printing, and textile machinery
• Wood, glass, ceramics, and stone processing equipment
• Automation systems and auxiliary motion axes

Download

Data Sheet (PDF)

Product Code:1FK7042-2AF71-1CG1-ZJ29X01
