1FK7042-2AF71-1CH0-ZV42 SIEMENS Exclusive SIMOTICS S-1FK7 Compact Synchronous Motor Original Brand New
$3,153.04
The SIEMENS SIMOTICS S-1FK7 motor (1FK7042-2AF71-1CH0-ZV42) is a compact, high-performance synchronous motor with integrated absolute encoder and optional planetary gearing, ideal for versatile industrial applications including robotics, packaging, and machine tools.
1FK7042-2AF71-1CH0-ZV42 SIEMENS Exclusive SIMOTICS S-1FK7 Compact Synchronous Motor Original Brand New
The SIEMENS SIMOTICS S-1FK7 synchronous motor with part number 1FK7042-2AF71-1CH0-ZV42 delivers exceptional performance for advanced automation and precision machinery. This compact motor is rated at 0.82 kW and operates at 600 V DC with a nominal speed of 3000 r/min. Equipped with a naturally cooled design (IMB 5, IM V1/V3), the motor ensures efficient heat dissipation without external cooling. Its robust construction includes a plain shaft with N tolerance and a holding brake, offering reliable operation in demanding environments. The integrated absolute encoder (24 bit + 12 bit multiturn) with DRIVE-CLiQ interface guarantees precise speed and position control for complex applications.
Overview
The SIMOTICS S-1FK7 series represents a versatile line of permanent-magnet synchronous motors designed for universal industrial applications. Compact and lightweight, these motors provide space-saving installation while maintaining high power density. The series supports multiple configurations, including planetary gearing options such as the ALPHA LP+ LP 090-MO1, ensuring flexibility in machine design. By pairing SIMOTICS S-1FK7 motors with SINAMICS S120/S220 drives, users can achieve highly functional and powerful systems suitable for high-dynamic, high-inertia, or standard performance requirements.
Benefits and Applications
SIMOTICS S-1FK7 motors offer a wide array of benefits including minimal commissioning overhead, robust closed-loop control, and exceptional dynamic response due to low rotor inertia. The motors are ideal for precision applications such as machine tools, robots and handling systems, wood, glass, ceramics, and stone processing, as well as packaging, plastics, textile machinery, and printing systems. The integrated high-precision encoder ensures consistent speed and position feedback, reducing the need for manual adjustments and optimizing overall system efficiency. High overload capability allows these motors to handle variable load moments reliably, making them an excellent choice for modern automated machines.
Download
Product Code: 1FK7042-2AF71-1CH0-ZV42
More Siemens products at Turll.com
| Weight | 8.7 kg |
|---|
