1FK7042-2AK71-1CG1-ZJ23 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New

1FK7042-2AK71-1CG1-ZJ23 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New

The SIEMENS SIMOTICS S Synchronous Motor 1FK7042-2AK71-1CG1-ZJ23 represents an advanced generation of high-performance servo motors, combining exceptional precision, reliability, and compact construction. Designed for modern automation systems, this motor delivers a rated power of 0.94 kW with 3 Nm torque at 6000 rpm, ensuring smooth and efficient operation under demanding conditions. Its naturally cooled, IMB 5 design with a rotatable power connector and IP65 protection class ensures stable performance even in harsh industrial environments.

Equipped with a 24-bit + 12-bit multi-turn absolute encoder featuring the Drive-CLiQ interface (encoder AM24DQI), this SIMOTICS S model provides outstanding positional feedback and motion control accuracy. The integrated ALPHA SP+ planetary gear unit (1 stage, i = 5) enhances torque delivery while maintaining compact dimensions. Built without a holding brake and featuring a smooth shaft with N tolerance, it supports a wide range of machine configurations, ensuring flexible mechanical integration across multiple industries.

Overview

SIMOTICS S-1FK7 motors are compact permanent-magnet synchronous units optimized for precision and durability. Combined with SINAMICS S120 or S220 drive systems, they deliver exceptional control accuracy and operational efficiency. The built-in encoder system allows dynamic motion with excellent repeatability, while the self-cooling design dissipates heat efficiently through the motor housing, enabling continuous operation without external fans or liquid cooling.

• Extremely high power density allowing space-saving installation
• Suitable for universal automation and servo applications
• Low-inertia design for rapid dynamic response
• Reliable closed-loop control for variable load applications
• Minimal commissioning effort due to stable control behavior

Applications

The 1FK7042-2AK71-1CG1-ZJ23 is suitable for use in machine tools, packaging lines, industrial robots, printing presses, and material-handling systems. Its versatility also extends to the wood, glass, textile, and plastics industries, where smooth motion and precise control are essential for consistent product quality.

Download

Data Sheet (PDF)

Product Code: 1FK7042-2AK71-1CG1-ZJ23
