1FK7042-2AK71-1CH1-ZJ09 SIEMENS Exclusive SIMOTICS S-1FK7 Synchronous Motor Original Brand New

1FK7042-2AK71-1CH1-ZJ09 SIEMENS Exclusive SIMOTICS S-1FK7 Synchronous Motor Original Brand New

The SIMOTICS S-1FK7 synchronous motor from SIEMENS is a compact, high-performance permanent-magnet motor designed for industrial automation applications. Delivering 0.94 kW of rated power at 6000 rpm, this motor is naturally cooled and constructed with an IMB 5 flange design. It features a rotatable power connector and a robust 24-bit absolute encoder with 12-bit multi-turn capabilities via the Drive-CLiQ interface, enabling precise speed and position control in demanding systems.

Integrated with the ALPHA SP+ planetary gearing (I=10) and a smooth shaft with N tolerance, this motor provides reliable torque and high dynamic performance. Its holding brake ensures operational safety, while the IP65 protection guarantees resistance against dust and water ingress. The design allows for seamless integration with SINAMICS S120/S220 drive systems, forming a high-functionality, fully synchronized system suitable for a variety of industrial tasks.

Overview

SIMOTICS S-1FK7 motors are engineered to meet the requirements of modern machine generations. The compact form factor, combined with high power density, allows space-saving installation without compromising performance. The expanded product range, including various encoder and gearbox options, ensures that each motor can be customized precisely for specific applications.

Benefits

• Extremely high power density allows efficient use of installation space
• Universal applicability across multiple industrial sectors
• High dynamic response thanks to a low rotor moment of inertia
• Robust closed-loop control for high or variable load inertia
• Minimal commissioning time and reduced optimization overhead

Applications

• Machine tools
• Robotics and handling systems
• Wood, glass, ceramics, and stone processing
• Packaging, plastics, and textile machines
• Printing machines
• Auxiliary axes in complex machinery

Download

Data Sheet (PDF)

Product Code: 1FK7042-2AK71-1CH1-ZJ09
