1FK7042-2AK71-1DG2 SIEMENS Exclusive SIMOTICS S-1FK7 Synchronous Motor Original Brand New
$1,682.39
The SIEMENS SIMOTICS S-1FK7 (1FK7042-2AK71-1DG2) is a compact, high-precision synchronous motor designed for demanding industrial automation applications, delivering reliable torque and smooth operation with DRIVE-CLiQ feedback and IP65 protection.
1FK7042-2AK71-1DG2 SIEMENS Exclusive SIMOTICS S-1FK7 Synchronous Motor Original Brand New
The SIEMENS SIMOTICS S-1FK7 motor (1FK7042-2AK71-1DG2) represents a new standard of precision, efficiency, and mechanical reliability for industrial automation. This compact permanent-magnet synchronous motor is designed to deliver superior torque and consistent rotational accuracy across demanding motion control systems. With a rated power of 0.94 kW and a nominal speed of 6000 rpm, it offers high-performance motion for machines that require exact synchronization and durability.
Built with natural cooling and an IP65-rated housing, the motor ensures long-term stability and minimal maintenance even under continuous load. The rotatable power connector simplifies installation in confined spaces, while the integrated incremental encoder IC22DQ with DRIVE-CLiQ interface provides precise feedback for speed and position control. Its plain shaft design and tolerance class N ensure a secure mechanical fit for a variety of couplings and load configurations.
Overview
The SIMOTICS S-1FK7 series from SIEMENS is engineered for seamless integration with SINAMICS S120 or S220 drive systems, forming a robust motion platform that supports diverse automation requirements. These motors combine flexibility with dynamic performance, enabling their use in multi-axis configurations and high-precision control applications. Each unit is optimized for operation without external cooling; thermal management is achieved through efficient surface heat dissipation, ensuring consistent performance across a wide temperature range.
Benefits
- Compact footprint and high power density for space-restricted installations
- Flexible mounting in IMB 5 (IM V1, IM V3) positions
- Multiple encoder and gearbox combinations for any motion profile
- Reliable overload capacity for continuous or cyclic loads
- Compatible with numerous mechanical and control system architectures
Applications
Ideal for precision machinery such as metalworking tools, robotics, packaging lines, and processing systems for wood, glass, ceramics, or textiles. Its responsive dynamics also make it suitable for printing and auxiliary drive tasks requiring exceptional smoothness and control.
Download
Product Code: 1FK7042-2AK71-1DG2
Find more Siemens products at Turll.com
| Weight | 4.602 kg |
|---|
