1FK7042-2AK71-1PH0-ZV40 SIEMENS Exclusive SIMOTICS S Synchronous Motor with ALPHA LP+ Planetary Gear Original Brand New

1FK7042-2AK71-1PH0-ZV40 SIEMENS Exclusive SIMOTICS S Synchronous Motor with ALPHA LP+ Planetary Gear Original Brand New

The SIEMENS SIMOTICS S 1FK7042-2AK71-1PH0-ZV40 is a high-performance synchronous motor designed for applications requiring precision, reliability, and compact power delivery. This exclusive unit combines a permanent-magnet synchronous motor with the proven ALPHA LP+ LP 090-MO1 planetary gearing, offering exceptional torque and efficiency for demanding industrial automation tasks. Engineered for a rated output of 0.94 kW, rated torque of 3 Nm, and speed up to 6000 rpm, the motor ensures accurate control with a rotatable 2-pole resolver and DRIVE-CLiQ interface.

Featuring a naturally cooled design in IMB 5 construction (IM V1, IM V3 mounting positions) and IP64 protection, this SIMOTICS S motor offers long-term durability even in challenging environments. The integrated holding brake and smooth shaft design provide stable performance and reduced maintenance requirements. Combined with SINAMICS S120 or S220 drives, it forms a highly responsive motion control system suitable for precision machinery and robotic solutions.

Overview

SIMOTICS S-1FK7 motors are compact, permanent-magnet synchronous motors designed for versatile machine-building applications. The broad selection of encoders, gear units, and mechanical options allows perfect adaptation to specific requirements. Their compact dimensions enable space-saving installations while maintaining excellent torque-to-size ratios.

• High power density for universal use
• Excellent dynamic response through low rotor inertia
• Stable control for varying load conditions
• Optimized for mechanical precision and energy efficiency

Applications

This motor is ideal for machine tools, robotics, packaging, textile, and printing equipment. It is equally suited for automated handling systems and auxiliary axes where accuracy, reliability, and smooth operation are critical.

Download

Data Sheet (PDF)

Product Code: 1FK7042-2AK71-1PH0-ZV40
