1FK7042-2AK71-1RH1-ZJ32 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New

1FK7042-2AK71-1RH1-ZJ32 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New

The SIEMENS SIMOTICS S represents cutting-edge motion control technology designed for superior precision and long-term reliability in demanding industrial environments. This synchronous motor delivers a continuous torque of 3 Nm and a rated power of 0.94 kW at 6000 rpm, providing stable and efficient performance for high-speed applications. With a 600 V DC supply, natural cooling, and IMB 5 construction (IM V1, IM V3), this model ensures durability and consistent operation even in challenging production settings.

The motor integrates an absolute 20-bit + 12-bit multi-turn encoder with Drive-CLiQ interface (AM20DQI), offering precise position feedback for advanced automation tasks. The addition of a smooth shaft with holding brake and IP65 protection ensures it can handle continuous use with minimal maintenance. Furthermore, the ALPHA SP+ SP 060S-MF2 planetary gearing (J32 variant) offers a two-stage reduction ratio of 16:1, enabling optimized torque transmission for motion systems that require fine-tuned accuracy and responsiveness.

Overview

SIMOTICS S-1FK7 motors are compact permanent-magnet synchronous motors known for their high power density and versatility. With multiple encoder and gearbox options, these motors can be adapted to a wide range of industrial applications, ensuring compatibility with modern automation demands. When combined with SINAMICS S120 or S220 drive systems, they deliver high performance and reliability, creating a seamless control solution for dynamic motion applications.

Benefits

• Compact design saves valuable space and supports flexible installation
• Exceptional precision and dynamic performance with minimal vibration
• Multiple motor variants for universal and dynamic requirements
• Excellent thermal management through natural convection cooling
• Easy integration with SIMOTICS and SINAMICS ecosystems

Applications

The 1FK7042-2AK71-1RH1-ZJ32 is ideal for a broad spectrum of automation systems, including:

• Machine tools and robotic systems
• Packaging, plastics, and textile machinery
• Wood, glass, ceramics, and stone processing equipment
• Printing machines and auxiliary motion axes

Download

Data Sheet (PDF)

Product Code: 1FK7042-2AK71-1RH1-ZJ32
