1FK7042-2AK74-1GG0 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New

1FK7042-2AK74-1GG0 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New

The SIEMENS SIMOTICS S is an exclusive high-performance synchronous motor engineered for precision, reliability, and long-term durability. Designed to deliver efficient torque and outstanding speed control, this motor is ideal for advanced automation and motion control applications. With a rated power of 0.94 kW, torque of 3 Nm, and a rated speed of 6000 rpm, it ensures excellent responsiveness and stability across a wide range of industrial operations.

This compact and naturally cooled servo motor is part of the renowned SIMOTICS S 1FK7 series, known for its superior energy efficiency and mechanical robustness. It features a plain shaft design, IP64 protection, and a rotatable power connector for flexible installation in various mounting positions. Equipped with a PT1000 temperature sensor and an AM32S/R absolute encoder (single-turn 4096 steps, multi-turn 4096 rotations) with EnDat interface, it provides high-resolution feedback and reliable position accuracy for closed-loop control systems.

Overview

SIMOTICS S-1FK7 motors are compact permanent-magnet synchronous motors designed for high precision and efficiency. Their modular design and wide variety of encoders, shafts, and mounting options make them suitable for nearly any machine concept. When combined with SINAMICS S120 / S220 drive systems, they form a dynamic and powerful motion solution with advanced functionality for speed and torque control. Heat dissipation is achieved through the motor housing, eliminating the need for external cooling and ensuring high operational reliability even under continuous load.

Benefits

• Compact size with exceptionally high power density for space-saving installation
• Universal usability across a wide range of automation systems
• High dynamic response with low rotor inertia for fast acceleration
• Reliable operation with minimal commissioning effort
• Optimized for applications requiring precision positioning and rapid motion cycles

Applications

The SIMOTICS S 1FK7042-2AK74-1GG0 is ideally suited for machine tools, robotic systems, and automated handling equipment. It also delivers excellent performance in packaging machinery, printing systems, textile production, and wood, glass, and stone processing applications. Its versatility makes it a preferred choice for industries demanding compact size, accuracy, and energy efficiency.

Download

Data Sheet (PDF)

Product Code: 1FK7042-2AK74-1GG0
