1FK7042-2AK74-1GH0 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New

1FK7042-2AK74-1GH0 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New

This is an advanced drive component engineered for high-precision motion control applications. Designed for superior performance and reliability, this motor delivers 0.94 kW of power and a nominal torque of 3 Nm at 6000 rpm. With its naturally cooled frame and IP64 protection, it ensures long-lasting operation even in demanding industrial environments. Its compact design and high power density make it an ideal choice for space-limited installations that require consistent performance and precision.

The 1FK7042-2AK74-1GH0 motor is equipped with an absolute encoder (AM32S/R) offering 32 S/R single-turn and 4096 rotation multi-turn resolution via an EnDat interface, ensuring accurate feedback for speed and position control. The rotatable power connector and integrated PT1000 temperature sensor provide flexibility and enhanced monitoring capabilities. With its plain shaft and integrated holding brake, this synchronous motor offers stability and safety during start-up and shutdown phases.

Overview

SIMOTICS S-1FK7 motors represent SIEMENS’ compact and versatile permanent-magnet synchronous motor line. Their modular structure, combined with a wide range of encoders and gearboxes, allows seamless adaptation to various industrial applications. The SIMOTICS S-1FK7 series meets the high demands of modern machine design, combining efficiency with flexibility and long-term reliability.

• Compact design for space-saving installation and high power density
• Exceptional dynamic response and smooth motion control
• High overload capacity for reliable performance under varying loads
• Compatible with SINAMICS S120/S220 drive systems
• Designed for operation without external cooling

Applications

This motor is suitable for machine tools, robotics, handling systems, packaging, printing, and textile machinery. It’s also widely used in wood, glass, and ceramic processing systems where speed precision and reliability are essential.

Download

Data Sheet (PDF)

Product Code: 1FK7042-2AK74-1GH0
