1FK7043-4CH71-1QB2 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New

1FK7043-4CH71-1QB2 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New

The SIEMENS 1FK7043-4CH71-1QB2 SIMOTICS S Synchronous Motor represents the next generation of high-efficiency motion technology designed for modern automation. With a rated power output of 1.2 kW and a nominal torque of 3.5 Nm, this motor delivers outstanding precision and performance across a wide range of industrial applications. Operating at a nominal speed of 4500 rpm and a rated voltage of 600 V DC, the unit provides smooth and responsive torque characteristics ideal for high-performance machinery. The compact, naturally cooled design ensures efficient heat dissipation through its frame surface, reducing energy loss and maintaining operational stability in demanding environments.

Built with a rotatable power connector and an absolute encoder single-turn 20-bit with DRIVE-CLiQ interface (AS20DQI), this motor enables precise position feedback and seamless integration with SINAMICS S120 or S220 drive systems. The robust mechanical structure, featuring a fitted key shaft and integrated holding brake, ensures excellent durability and safety. With protection degrees of IP65 (housing) and IP67 (flange), this synchronous motor is engineered for long-term reliability even in dusty or moisture-prone environments. It is a trusted choice for advanced automation systems requiring high precision and continuous duty performance.

Overview

The SIMOTICS S-1FK7 series combines compact construction with superior torque density, offering remarkable flexibility for engineers and system integrators. This motor family supports a variety of encoder systems, gear units, and cooling configurations, allowing easy adaptation to different performance needs. When used with compatible Siemens drives, these motors achieve an exceptional balance of efficiency, accuracy, and dynamic response. The SIMOTICS S-1FK7 range also supports seamless connectivity through standardized interfaces, simplifying commissioning and reducing integration time.

Benefits

• Compact and space-saving design with high power density
• Available in various configurations for diverse industrial requirements
• Fast and smooth dynamic response due to low rotor inertia
• Reliable closed-loop control for applications with fluctuating load inertia
• Reduced commissioning time and minimal tuning effort

Applications

The SIMOTICS S-1FK7 motor family is suitable for an extensive range of industrial equipment, including:

• Machine tools and precision robotics
• Material handling and automated assembly systems
• Woodworking, glass, ceramics, and stone processing machinery
• Packaging, plastics, and textile machines
• High-speed printing and auxiliary motion systems

Download

Data Sheet (PDF)

Product Code: 1FK7043-4CH71-1QB2
