1FK7044-4CF71-1RG0-ZV40 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New
$2,641.94
The SIEMENS SIMOTICS S 1FK7044-4CF71-1RG0-ZV40 synchronous motor delivers 1.2 kW power and 4.5 Nm torque with a planetary gearbox for precision, reliability, and compact industrial performance.
1FK7044-4CF71-1RG0-ZV40 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New
The SIEMENS SIMOTICS S 1FK7044-4CF71-1RG0-ZV40 is a high-precision synchronous motor engineered for superior dynamic performance and reliability in demanding industrial environments. This advanced servo motor delivers 1.2 kW nominal power with a rated torque of 4.5 Nm and a base speed of 3000 rpm. Operating on a 600 V DC supply, it is naturally cooled and designed in IMB 5 (IM V1, IM V3) mounting configuration. Equipped with an AM20DQI multi-turn absolute encoder featuring 20-bit + 12-bit resolution and a DRIVE-CLiQ interface, it ensures precise feedback and synchronization with SINAMICS drives. This variant also includes an ALPHA LP+ LP 090-MO1 planetary gearbox with a one-stage ratio of 5:1, providing robust torque transmission and accurate motion control for complex automation systems.
Overview
The SIMOTICS S-1FK7 series is Siemens’ proven solution for dynamic, space-efficient, and energy-optimized motor applications. These permanent-magnet synchronous motors combine compact dimensions with exceptional mechanical robustness and high torque density. Their modular design allows flexible adaptation to a wide range of industrial applications through various encoder options, gear units, and mechanical interfaces. When integrated with the SINAMICS S120 or S220 drive system, they form a complete servo solution offering high precision, rapid acceleration, and consistent motion accuracy. The 1FK7 family supports sensorless operation and excellent overload capacity, ensuring consistent performance under fluctuating load conditions.
Design and Benefits
The 1FK7044-4CF71-1RG0-ZV40 model features a plain shaft with standard tolerance and operates without a holding brake, reducing mechanical complexity and improving efficiency. The naturally cooled housing efficiently dissipates heat via the surface, ensuring long service life and stable operation. With an IP64 protection rating, it is safeguarded against dust and splashing water, making it ideal for diverse industrial settings. The included planetary gearbox provides smooth transmission and enhanced precision for motion control. Designed for universal use, this motor is commonly deployed in machine tools, packaging lines, robotics, and automation systems. Its compact form factor enables space-saving installation while maintaining high torque output and dynamic response.
Download
Product Code: 1FK7044-4CF71-1RG0-ZV40
Discover more Siemens products at Turll.com
| Weight | 11.201 kg |
|---|
