1FK7044-4CF71-1UG1 SIEMENS Exclusive High Dynamic Synchronous Motor Original Brand New

1FK7044-4CF71-1UG1 SIEMENS Exclusive High Dynamic Synchronous Motor Original Brand New

The SIEMENS SIMOTICS S-1FK7 1FK7044-4CF71-1UG1 is a premium-grade synchronous servo motor engineered for precision, reliability, and outstanding efficiency. Delivering a rated power of 1.2 kW and a torque of 4.5 Nm at 3000 rpm, this high-performance motor is ideally suited for advanced industrial automation systems that require compact design and exceptional dynamic response. The unit operates with a 600 V DC link voltage and features a naturally cooled configuration, ensuring consistent performance under continuous operation. Its plain shaft, resolver feedback with DRIVE-CLiQ interface, and IP65 protection rating make it an excellent choice for demanding machine environments where durability and precision are essential.

Overview

The SIMOTICS S-1FK7 motor series represents Siemens’ most flexible range of compact permanent-magnet synchronous motors. Thanks to a wide selection of encoder systems, gear combinations, and mounting options, the S-1FK7 family can be adapted to almost any automation application. When combined with SINAMICS S120 or S220 drive systems, these motors provide powerful and highly accurate motion control for both standard and high-end machinery. The integrated encoder enables smooth speed and position control, while the surface-cooled construction ensures efficient heat dissipation without the need for external fans. High overload capability and robust construction further enhance operational stability and service life.

Benefits

• Compact and lightweight design allowing for space-saving installation
• High torque density for optimized mechanical performance
• Exceptional control accuracy with integrated resolver and DRIVE-CLiQ feedback
• Low moment of inertia for rapid acceleration and deceleration cycles
• Durable IP65 housing providing excellent protection against dust and moisture
• Seamless integration with Siemens automation systems

Applications

This motor is ideal for a variety of industrial fields, including machine tools, robotic systems, material handling, and packaging. It is also well-suited for production in wood, glass, ceramics, textile, and printing machinery where high-precision motion and reliability are crucial.

Download

Data Sheet (PDF)

Product Code: 1FK7044-4CF71-1UG1
