1FK7060-2AC71-1FA2 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New

1FK7060-2AC71-1FA2 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New

The SIEMENS SIMOTICS S Synchronous Motor 1FK7060-2AC71-1FA2 is a high-performance servo motor designed for precise, reliable, and energy-efficient motion control across a wide range of industrial applications. With a continuous torque of 6 Nm, rated speed of 2000 rpm, and a rated power of 1.1 kW, this motor provides outstanding dynamic response and torque accuracy for modern automation systems. It operates at a DC voltage of 600V and features a robust IMB 5 flange-mounted design, ensuring easy installation and compatibility with standard mechanical interfaces.

The motor is equipped with a 22-bit + 12-bit multiturn absolute encoder with DRIVE-CLiQ interface (Encoder AM22DQ) for high-resolution position feedback and enhanced control precision. Its naturally cooled design ensures reliable heat dissipation without the need for external fans, making it suitable for compact installations and continuous operation. With a degree of protection of IP65 on the body and IP67 on the flange, it delivers long-lasting performance even under demanding environmental conditions. The rotatable power connector and shaft with fitted key (tolerance N) provide flexible mounting and mechanical adaptability, while the absence of a holding brake simplifies integration into systems where free motor rotation is required.

Overview

SIMOTICS S-1FK7 motors are compact permanent-magnet synchronous motors engineered for efficiency, precision, and versatility. The extended range of gearboxes and encoders allows them to be perfectly configured for numerous industrial applications. When combined with the SINAMICS S120 or S220 drive systems, they form a powerful and intelligent motion solution capable of handling complex motion control tasks with exceptional accuracy. The integrated encoder systems support both speed and position feedback for smooth and dynamic control.

Benefits

• Extremely compact design with high power density for space-saving installations
• Flexible application range suitable for universal automation needs
• Excellent dynamic response with low rotor moment of inertia
• Rugged construction and high overload capability
• Optimized for minimal maintenance and long operational life

Applications

• Machine tools and robotics
• Packaging, textile, and plastic processing systems
• Wood, glass, ceramics, and stone machinery
• Printing and material handling applications
• Auxiliary and positioning axes in automation

Download

Data Sheet (PDF)

Product Code: 1FK7060-2AC71-1FA2
