1FK7060-2AC71-1RG0-ZV40 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New

1FK7060-2AC71-1RG0-ZV40 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New

The SIEMENS 1FK7060-2AC71-1RG0-ZV40 SIMOTICS S is a high-performance synchronous motor designed for demanding industrial applications. This compact permanent-magnet motor delivers 1.1 kW nominal power with a rated voltage of 600 V and a torque of 6 Nm at 2000 rpm, making it ideal for precision machinery requiring reliable speed and position control. With naturally cooled construction and IP64 protection, this motor ensures safe, continuous operation even in challenging environments. The rotatable power connector and absolute encoder with 20-bit + 12-bit multi-turn capabilities via Drive-CLiQ interface (AM20DQI) provide precise feedback for automation systems.

Engineered for versatility, the 1FK7060-2AC71-1RG0-ZV40 model is equipped with a smooth shaft and tolerance N, and includes ALPHA LP+ planetary gearing, 1 stage with a ratio of 5, offering superior mechanical integration. Its combination of compact design, high power density, and modular interface options enables seamless adaptation to a wide range of industrial setups, from robots and machine tools to auxiliary axes in packaging and plastics machines.

Overview

The SIMOTICS S‑1FK7 series is built for flexibility and high functionality. These motors integrate seamlessly with SINAMICS S120/S220 drive systems, providing a complete solution for speed and position control. Thanks to advanced encoder technology, operators can achieve accurate and repeatable motion control with minimal calibration effort. The motors operate efficiently without external cooling, dissipating heat directly through the motor surface while maintaining a high overload capability. Available gearboxes and encoder options expand the application possibilities, enabling adaptation to modern machine requirements.

Benefits

• Compact design allows space-saving installation without compromising performance
• High dynamic response for applications with low rotor inertia requirements
• Robust performance for high-inertia applications with minimal commissioning effort
• Wide range of configurable options for universal industrial use

Applications

• Machine tools for precision machining
• Robots and automated handling systems
• Wood, glass, ceramics, and stone processing machines
• Packaging, plastics, and textile machinery
• Printing machines and auxiliary axes

Download

Data Sheet (PDF)

Product Code: 1FK7060-2AC71-1RG0-ZV40
