1FK7060-2AC71-1RG2 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New

1FK7060-2AC71-1RG2 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New

The SIEMENS SIMOTICS S 1FK7-CT motor is a high-performance permanent-magnet synchronous motor designed for precision-driven industrial applications. With a nominal power of 1.1 kW and a rated speed of 2000 rpm, this motor combines compact design with exceptional efficiency. Its naturally cooled IMB 5 construction (IM V1, IM V3) and robust flange design allow seamless integration into various machines without additional cooling systems. The motor includes a rotatable power connector and a 20-bit absolute encoder complemented by a 12-bit multi-turn encoder with Drive-CLiQ interface, ensuring precise speed and position control.

Engineered for demanding environments, the 1FK7060-2AC71-1RG2 offers smooth shaft operation with N tolerance and enhanced protection levels: IP65 on the DE flange and IP67 for the motor housing. Its versatility allows pairing with SINAMICS S120 or S220 drives to create an advanced, fully integrated system capable of handling dynamic and high-inertia tasks with minimal setup. The integrated encoder ensures accurate feedback for automated processes, making it ideal for robotics, machine tools, and high-precision manufacturing equipment.

Overview

The SIMOTICS S 1FK7 series provides compact and efficient synchronous motors for a wide range of applications. Available options, including gearboxes and encoders, make the motors adaptable to modern machines with varying power requirements. They are designed to dissipate heat naturally through the motor surface, eliminating the need for external cooling systems. High overload capacity and robust design ensure long-term reliability even under continuous operation in challenging industrial environments.

Benefits & Applications

• Space-saving installation due to high power density
• Universal suitability for diverse industrial tasks
• High-dynamic response with low rotor inertia for precise control
• Optimized for high-inertia applications, providing stable closed-loop performance
• Minimal commissioning and adaptation overhead

These motors are ideal for machine tools, robotic handling systems, woodworking, glass, ceramics, stone, packaging, plastics, textiles, printing, and auxiliary axes. The combination of high precision, robust construction, and compatibility with advanced drive systems makes the 1FK7060-2AC71-1RG2 a versatile solution for modern industrial automation.

Download

Data Sheet (PDF)

Product Code: 1FK7060-2AC71-1RG2
