1FK7060-2AF71-1CB2 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New

1FK7060-2AF71-1CB2 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New

The SIEMENS 1FK7060-2AF71-1CB2 SIMOTICS S synchronous motor is engineered to deliver dependable torque performance, smooth motion control, and long-term operational reliability. With a rated power of 1.5 kW, a torque rating of 6 Nm at 100K, and a nominal speed of 3000 rpm, this motor provides the stability needed for modern automation systems. It features a naturally cooled IMB 5 configuration, suitable for both IM V1 and IM V3 mounting orientations, ensuring flexibility across various installation requirements. The integrated absolute encoder with 24-bit single-turn and 12-bit multiturn resolution, using DRIVE-CLiQ technology, enhances accuracy in closed-loop control applications.

This compact unit includes a rotatable power connector, shaft with feather key, standard tolerance class N, and an integrated holding brake. Its robust construction supports protection class IP65 on the drive end and IP67 at the flange, making it highly resistant to industrial environments. Designed for applications that require precise motion, responsive acceleration, and stable characteristics under variable loads, the motor represents a versatile solution for advanced machine designs.

Overview

The SIMOTICS S-1FK7 motor series consists of compact permanent-magnet synchronous motors designed for a wide spectrum of automation tasks. With an expanded selection of options, encoder variations, and gearbox compatibility, the 1FK7 family provides adaptability across numerous industrial sectors. When paired with SINAMICS S120 or S220 drive systems, the motors form a powerful, high-performance motion control platform.

These motors are designed for operation without external cooling, utilizing surface dissipation to maintain thermal stability. They offer excellent overload capability, making them suitable for dynamic operating cycles. Depending on application needs, users can select between compact, high-dynamic, or high-inertia variants—each optimized for performance, response, or load stability.

Benefits

• Compact format enabling space-efficient installation
• Flexible adaptation through broad configuration options
• High dynamic performance due to low-inertia rotor variants
• Stable closed-loop behavior for demanding load conditions
• Reduced commissioning time thanks to refined control characteristics

Application

• Machine tools
• Robotics and handling systems
• Wood, glass, ceramic, and stone processing machinery
• Packaging, plastic, and textile machines
• Printing systems and auxiliary axes

Download

Data Sheet (PDF)

Product Code:1FK7060-2AF71-1CB2
