1FK7060-2AF71-1CG1-ZJ03 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New
$4,078.80
A high-performance SIEMENS SIMOTICS S motor featuring precise feedback, robust mechanical design, and an SP+ planetary gearbox for demanding automated motion applications.
1FK7060-2AF71-1CG1-ZJ03 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New
The SIEMENS SIMOTICS S synchronous motor with product designation 1FK7060-2AF71-1CG1-ZJ03 is a premium motion control solution engineered for applications requiring high accuracy, smooth operation, and long-term reliability. This advanced motor is designed within the 1FK7-CT series, featuring a rated power of 1.5 kW, a 600 V DC link voltage, and a continuous stall torque of 6 Nm. With a nominal speed of 3000 rpm and a naturally cooled structure, it supports efficient thermal behavior without the need for external fans. The configuration follows the IMB 5 build form, including versatile mounting orientations that enhance installation flexibility for various motion-driven environments.
The motor integrates a precision absolute encoder system equipped with 24-bit resolution plus an additional 12-bit multiturn function through a DRIVE-CLiQ interface. This ensures outstanding position tracking, reliable feedback communication, and optimized synchronization with SINAMICS drive platforms. Its rotatable power connector and smooth shaft design provide convenience for integration into compact machinery. The IP65 degree of protection reinforces reliability against dust and water spray, making it suitable for demanding industrial conditions.
Overview
The SIMOTICS S-1FK7 1FK7060-2AF71-1CG1-ZJ03 motor family is recognized for its compact build, high power density, and excellent controllability. These motors are compatible with SINAMICS S120 or S220 drive systems, creating a high-performance motion package. They deliver notable overload capability, allowing stable operation even under dynamic load changes. With a wide selection of encoder systems, construction sizes, and gear options, the series supports an extensive range of machine concepts.
Design & Benefits
This configuration includes the ALPHA SP+ planetary gearing (SP 100S-MF1), offering a 1-stage gear ratio of i=5 with a feather key for secure power transmission. Its compact assembly supports applications with limited installation space while providing excellent torque multiplication. Among the key advantages of the 1FK7 platform are:
- High power density enabling reduced machine footprint
- Flexible adaptation to numerous industrial applications
- Very dynamic motion behavior for precise positioning
- Reliable closed-loop performance even with variable loads
- Lower commissioning effort due to optimized system integration
Application
Typical applications include machine tools, industrial robots, automated handling systems, woodworking equipment, ceramic and stone machinery, packaging lines, textile processing machines, printing systems, and various auxiliary machine axes. Its robust design, precise feedback, and strong motor-gearbox combination make it an excellent choice for high-performance automation.
Download
Product Code: 1FK7060-2AF71-1CG1-ZJ03
Discover more Siemens products at Turll.com.
| Weight | 14.801 kg |
|---|
