1FK7060-2AF71-1CH0-ZV40 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New

1FK7060-2AF71-1CH0-ZV40 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New

The SIEMENS SIMOTICS S 1FK7060-2AF71-1CH0-ZV40 represents a high-performance synchronous motor engineered to deliver precision, reliability, and efficiency in demanding machine applications. Designed with a compact structure and high power density, this model provides a rated power of 1.5 kW, nominal torque of 6 Nm, and nominal speed of 3000 rpm. Its naturally cooled construction ensures quiet operation, while the IMB 5 mounting type enables flexible integration into a wide range of machine configurations. The motor is equipped with a robust 24-bit + 12-bit multiturn absolute encoder featuring the DRIVE-CLiQ interface, supporting accurate control in dynamic environments.

This variant includes a smooth shaft with holding brake, IP64 protection, and a rotatable power connector for simplified installation. The ZV40 configuration integrates the ALPHA LP+ 120-MO1 planetary gearbox, offering a reduction ratio of i = 5 with a fitted key. This combination enhances output torque, improves mechanical precision, and supports applications requiring precise positioning. The motor’s compact build, high overload capability, and adaptable configuration make it suitable for a wide variety of industrial tasks.

Overview

SIMOTICS S-1FK7 motors are permanent-magnet synchronous motors designed for modern industrial environments that demand efficiency and dynamic performance. Their modular options, such as advanced encoder systems and mechanical gear units, allow customization for highly specialized tasks. Compact dimensions and high power density enable space-optimized installation, making them a preferred choice for next-generation machinery.

When combined with SINAMICS S120 or S220 drive systems, these motors deliver superior functionality for applications requiring precise speed and position control. Their design enables operation without external cooling equipment, using the motor surface for thermal dissipation. The series supports high overload ratings, ensuring performance stability under fluctuating mechanical loads.

Benefits

• Compact dimensions for space-saving installation
• Wide compatibility for universal industrial applications
• Available in multiple performance classes and frame sizes
• High dynamic response thanks to low rotor inertia
• Stable closed-loop characteristics for varying load conditions
• Reduced commissioning effort due to robust control properties

Application

• Machine tools
• Robotics and automation handling systems
• Wood, glass, stone, and composite processing
• Packaging, plastics, and textile machinery
• Printing systems and auxiliary axes

Download

Data Sheet (PDF)

Product Code: 1FK7060-2AF71-1CH0-ZV40
