1FK7060-2AF71-1CH1-ZJ12 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New

1FK7060-2AF71-1CH1-ZJ12 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New

The SIEMENS SIMOTICS S motor with model designation 1FK7060-2AF71-1CH1-ZJ12 is engineered for applications that demand precision, consistency, and superior mechanical performance. Delivering a rated power of 1.5 kW and operating with a 600 V DC link, the motor provides a continuous torque of 6 Nm and supports speeds up to 3000 rpm. Its efficient natural cooling concept ensures dependable thermal balance without external cooling components, supporting long-term operational reliability across a wide variety of industrial processes.

This configuration includes a high-resolution 24-bit absolute encoder paired with a 12-bit multiturn system and DRIVE-CLiQ interface, enabling highly accurate positioning feedback and smooth motion profiles. The rotatable power connector enhances installation flexibility, while the smooth shaft with N-class tolerances and holding brake improves integration into diverse mechanical assemblies. With an IP65 protection rating, the motor withstands dust and water exposure common in demanding industrial environments. The ZJ12 configuration incorporates an ALPHA SP+ planetary gearbox, providing a two-stage ratio of 16 for increased torque and refined mechanical output, making it suitable for advanced automation solutions.

Overview

The SIMOTICS S-1FK7 series is known for compact dimensions, excellent responsiveness, and versatile configuration options. Motors in this series are designed to match a wide range of automation tasks and integrate seamlessly with the SINAMICS S120 and S220 drive systems. High overload capability, durable construction, and easily selectable encoder options allow engineers to tailor each unit to meet performance requirements in precision-driven environments.

Key Features

• High power density for compact machine design
• Permanent-magnet synchronous technology for efficient operation
• Wide selection of mechanical and encoder options
• Excellent dynamic response across High Dynamic and High Inertia variants
• Stable closed-loop characteristics under varying load conditions

Application

• Machine tools and precision manufacturing systems
• Robotics and automated handling solutions
• Packaging, plastics, textile, and printing machinery
• Wood, glass, ceramics, and stone processing equipment
• Auxiliary axes for multi-axis automation frameworks

Download

Data Sheet (PDF)

Product Code:
1FK7060-2AF71-1CH1-ZJ12
