1FK7060-2AF71-1FB2 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New

1FK7060-2AF71-1FB2 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New

The SIEMENS SIMOTICS S 1FK7060-2AF71-1FB2 is a high-performance synchronous motor engineered for modern industrial automation, offering exceptional precision, efficiency, and long-term durability. This advanced motor features a natural cooling design, ensuring consistent thermal stability without requiring external cooling components. With a rated torque of 6 Nm, nominal speed of 3000 rpm, and a power rating of 1.5 kW, it is suitable for a wide range of dynamic motion applications.

The integrated absolute encoder with 22-bit single-turn resolution and 12-bit multi-turn capability enhances accuracy in demanding positioning tasks, while the DRIVE-CLiQ interface ensures seamless communication with SINAMICS drive systems. Additional features such as a fitted-key shaft, holding brake, and high protection class (IP65/IP67) further contribute to reliable operation in harsh industrial environments.

Overview

The SIMOTICS S-1FK7 series is widely known for its compact structure, high power density, and adaptability across diverse machine architectures. As permanent-magnet motors, they are optimized for dynamic response, precise speed control, and smooth operation. When paired with SINAMICS S120 or S220 drive platforms, the system delivers superior performance in applications requiring synchronized motion, multi-axis control, or advanced automation strategies. With several encoder variants and mechanical options available, the 1FK7 range supports tailored motor configurations that match specific engineering needs.

Benefits

• Space-saving format due to exceptional power density
• Highly adaptable to both standard and custom machine environments
• Available in a wide variety of torque, speed, and size variants
• Fast dynamic response enabled by optimized rotor design
• Stable closed-loop behavior even under changing load conditions
• Reduced commissioning effort and simplified optimization

Application

• Machine tools and precision cutting systems
• Robotics and automated handling equipment
• Packaging, plastic, textile, and printing machinery
• Wood, ceramic, glass, and stone processing equipment
• Auxiliary axes requiring dependable motion control

Product Code: 1FK7060-2AF71-1FB2
