1FK7060-2AF71-1FG0 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New

1FK7060-2AF71-1FG0 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New

The SIEMENS SIMOTICS S Synchronous Motor 1FK7060-2AF71-1FG0 in this configuration delivers exceptional precision, durability, and performance for modern automation environments. Engineered with a rated power of 1.5 kW and a nominal speed of 3000 rpm, the motor is built to operate efficiently in demanding motion control systems. Its naturally cooled design and IMB 5 mounting style make it suitable for compact machine layouts, while the rotatable power connector and plain shaft configuration ensure flexible installation across various mechanical setups. Equipped with a high-resolution 22-bit singleturn plus 12-bit multiturn absolute encoder with DRIVE-CLIQ interface, the motor provides accurate position feedback ideal for advanced servo applications.

This model belongs to the highly adaptable SIMOTICS S-1FK7 1FK7060-2AF71-1FG0 series, known for its compact dimensions and versatile performance characteristics. These motors are widely used in applications that demand consistent torque, stable operation, and high efficiency. With its robust IP64 degree of protection, the motor is designed to withstand harsh operating conditions, contributing to longer service life and reduced maintenance interruptions. The absence of a holding brake supports simplified structural integration and is suitable for systems where an external braking mechanism or drive-based braking is preferred.

Overview

The SIMOTICS S-1FK7 platform is recognized for its modularity and adaptability. This series integrates seamlessly with SINAMICS S120 and S220 drive systems, forming a highly responsive motion solution. The motors utilize advanced encoder technologies for effective speed and position control, and their thermal design enables efficient heat dissipation without external cooling equipment. High overload capability allows stable operation even under rapidly changing load conditions, making the motors ideal for modern machine tools and high-precision industrial systems.

Benefits

• Extremely compact construction for space-efficient installation
• Broad configuration range for universal applications
• High dynamic response achieved through low rotor inertia options
• Stable control performance with high inertia variants
• Reduced commissioning effort due to strong disturbance compensation

Application

• Machine tools and CNC systems
• Robotic arms and advanced handling units
• Wood, glass, ceramics, and stone processing machines
• Packaging, plastics, and textile equipment
• Printing systems and auxiliary motion axes

Download

Data Sheet (PDF)

Product Code: 1FK7060-2AF71-1FG0
