1FK7060-2AF71-1PB2 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New

1FK7060-2AF71-1PB2 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New

The SIEMENS 1FK7060-2AF71-1PB2 is a high-performance synchronous motor engineered for precision, reliability, and long-term operational stability. As part of the renowned SIMOTICS S-1FK7 series, this motor is built to support demanding industrial applications where consistent speed control, accurate position feedback, and exceptional energy efficiency are required. With a rated power of 1.5 kW, a rated torque of 6 Nm, and a nominal speed of 3000 rpm, it provides a balanced combination of power and responsiveness.

Its naturally cooled IMB 5 construction and robust flange design offer simplified integration across a wide range of mechanical configurations. The motor includes a rotatable power connector, a 2-pole resolver with DRIVE-CLiQ interface, and a durable shaft equipped with a feather key for secure coupling. The integrated holding brake and IP65/IP67 protection levels ensure mechanical safety and resistance in challenging industrial environments.

The SIMOTICS S-1FK7 platform is widely recognized for its compact structure and impressive power density. These motors are ideal for installations where space efficiency must be maintained without compromising performance or precision. Their capability to pair seamlessly with SINAMICS S120 or S220 drive systems results in a fully synchronized motion solution that delivers exceptional control dynamics. Depending on operational needs, users can select from a variety of encoder systems, enabling fine-tuned configuration for positioning, speed regulation, or automated motion profiles.

Overview

SIMOTICS S-1FK7 1FK7060-2AF71-1PB2 motors represent a modern generation of permanent-magnet synchronous motors designed to meet the increasing requirements of advanced machinery. Their modular options, encoder variants, and compatibility with a broad range of gearboxes allow them to be adapted to numerous industrial sectors. These motors support operation without external cooling systems, relying on optimized surface dissipation, and offer a high overload capacity to handle rapidly changing operational conditions.

Benefits

• Compact structure enabling installation in limited spaces
• Suitable for universal and specialized industrial applications
• Available in multiple performance categories for diverse needs
• High dynamic response due to optimized rotor design
• Stable control performance for variable load conditions
• Reduced commissioning time through advanced motor characteristics

Application

• Machine tools and precision equipment
• Robotic systems and automated handling
• Machinery for wood, ceramics, glass, and stone processing
• Packaging, plastic, and textile automation
• Printing machines and auxiliary axes

Download

Data Sheet (PDF)

Product Code: 1FK7060-2AF71-1PB2
