1FK7060-2AF71-1RG1-ZJ36 SIEMENS Exclusive SIMOTICS S-1FK7 Original Brand New

1FK7060-2AF71-1RG1-ZJ36 SIEMENS Exclusive SIMOTICS S-1FK7 Original Brand New

The 1FK7060-2AF71-1RG1-ZJ36 SIMOTICS S-1FK7 is a high-performance synchronous motor engineered for precision and efficiency in industrial applications. Delivering 1.5 kW of power at 3000 rpm, this compact permanent-magnet motor features a naturally cooled design, robust IP65 protection, and advanced absolute encoder systems for both speed and position monitoring. The rotatable power connector and smooth shaft design ensure flexibility during installation, while the integrated 20-bit plus 12-bit multiturn encoder with DRIVE-CLiQ interface provides accurate feedback for dynamic control. Equipped with an ALPHA SP+, SP 140S-MF2 planetary gearbox (2 stages, I=40) and no feather key, this motor is ready for integration into sophisticated machinery requiring high precision and reliability.

Overview

SIMOTICS S‑1FK7 motors are versatile, compact synchronous motors suitable for a wide range of automation applications. They are designed to deliver high power density in a minimal footprint, making them ideal for modern machine generations that require both precision and efficiency. The extensive range of available gearboxes and encoder configurations allows for adaptation to different performance requirements. These motors can be seamlessly combined with SINAMICS S120 and S220 drive systems to create highly functional motion control solutions.

The integrated encoder systems ensure precise position and speed control, optimizing performance in dynamic and variable load conditions. The naturally cooled design dissipates heat through the motor surface, eliminating the need for additional cooling devices, while maintaining a high overload capability for demanding operations.

Benefits and Applications

SIMOTICS S‑1FK7 motors offer several benefits depending on the type of motor configuration. Compact models enable space-saving installations and universal use across various industrial equipment. High dynamic versions provide extremely fast response due to the low rotor moment of inertia, while high inertia versions offer stable closed-loop control under variable load conditions, minimizing optimization and commissioning time.

Typical applications include machine tools, robots and handling systems, wood, glass, ceramic, and stone processing machines, as well as packaging, plastics, textile, and printing machinery. Auxiliary axes and other specialized industrial systems can also benefit from the precise and reliable performance of this motor.

Download

Data Sheet (PDF)

Product Code: 1FK7060-2AF71-1RG1-ZJ36
