High-precision synchronous motor with integrated multiturn encoder, natural cooling, planetary gearbox option, and durable industrial construction for advanced motion control.
The SIEMENS 1FK7060-2AF71-1RH1-ZJ13 is a high-performance synchronous motor engineered for advanced motion applications requiring accuracy, smooth operation, and long-term dependability. With a nominal torque rating of 6 Nm, a rated speed of 3000 rpm, and a DC link voltage of 600 V, this motor delivers reliable power in demanding machine environments. It features natural cooling and a durable construction optimized for IMB 5 mounting, making it suitable for vertical or horizontal configurations. The power connector is rotatable to support flexible installation, while the integrated absolute encoder (20-bit plus 12-bit multiturn) with DRIVE-CLiQ interface ensures outstanding feedback precision for position-regulated systems.
This 1FK7060-2AF71-1RH1-ZJ13 configuration includes the J13 option, which incorporates the ALPHA SP+ SP100S-MF2 two-stage planetary gearbox with a ratio of 20 and a feather key output. This gearbox is known for low backlash, high stiffness, and excellent transmission efficiency, enabling dynamic motion sequences and repeatable positioning in automation systems. The motor also includes a smooth shaft with holding brake and IP65 protection, ensuring dependable operation even in challenging industrial settings.
SIMOTICS S-1FK7 motors belong to a versatile portfolio of compact synchronous units designed to deliver high performance across a wide range of industries. These motors combine efficient electromagnetic design with compact construction, making them ideal for applications where installation space is limited. When paired with SINAMICS S120 or S220 drive systems, they offer a powerful and flexible platform capable of handling complex motion profiles with stability and responsiveness.
The product family provides a broad spectrum of characteristics such as high power density, robust control behavior, low rotor inertia options for dynamic tasks, and optimized thermal design for continuous-duty performance. These motors reduce commissioning effort thanks to advanced encoder technology and integrated diagnostics.
Common use cases include machine tools, robotic handling, packaging equipment, material-processing machines, printing systems, and various auxiliary axes in automated production lines.
Product Code:
1FK7060-2AF71-1RH1-ZJ13
More Siemens products at Turll.com
| SKU / Model | 1FK7060-2AF71-1RH1-ZJ13 |
|---|---|
| Weight | 15.3 kg |
