The SIEMENS 1FK7060-2AF74-1SB0 SIMOTICS S synchronous motor is a high-performance compact permanent-magnet motor engineered for modern industrial applications. Delivering 1.5 kW of nominal power with a rated voltage of 600 V, this motor operates at 3000 rpm and incorporates a naturally cooled design. It is built to IMB 5 standards (IM V1, IM V3) with flange 1 mounting, featuring a robust multi-pole resolver (P=4) for precise position feedback.

A Pt1000 temperature sensor provides reliable thermal monitoring, and the rotatable power connector ensures flexible installation. The shaft is equipped with a feather key and tolerance N, while the integrated holding brake offers additional operational safety. With an IP64 degree of protection, the motor is well-suited for environments requiring dust and splash water resistance.

Overview

The SIMOTICS S‑1FK7 1FK7060-2AF74-1SB0 series represents a versatile range of synchronous motors designed for integration with SINAMICS S120/S220 drive systems. These motors combine compact construction with high power density, making them suitable for space-limited installations. The available variants, including high dynamic and high inertia models, allow adaptation to diverse applications, from machine tools and robots to packaging, printing, and textile machinery. Integrated encoders facilitate precise speed and position control tailored to specific operational requirements. Designed to dissipate heat naturally, the motors operate efficiently without external cooling while providing high overload capability and long service life.

Benefits

SIMOTICS S‑1FK7 motors offer several advantages for industrial use. Compact models save installation space and can handle universal applications, while high dynamic versions provide exceptionally fast response due to low rotor inertia. High inertia variants ensure robust closed-loop control under variable or high load conditions, reducing commissioning overhead. These motors are optimized for seamless integration into automated systems and can handle demanding operational scenarios with minimal adjustments.

Application

Typical applications include machine tools, robots and handling systems, woodworking, glass, ceramics and stone processing, packaging machines, plastics and textile equipment, printing machinery, and auxiliary axes requiring precise and reliable motion.

Product Code: 1FK7060-2AF74-1SB0
