1FK7061-4CF71-1BG0 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New

1FK7061-4CF71-1BG0 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New

The SIEMENS 1FK7061-4CF71-1BG0 SIMOTICS S motor is a high-quality synchronous unit engineered for precision, reliability, and consistent performance in demanding industrial environments. This model delivers 1.7 kW rated power, operates at 600 V DC, and provides 6.4 Nm continuous torque at 100 K. With a nominal speed of 3000 rpm and a naturally cooled design, it ensures efficient thermal behavior without requiring additional cooling infrastructure. The compact IMB 5 construction and rotatable power connector make integration flexible and suitable for applications where space optimization and adaptable mounting are essential. Its IP64 protection rating supports long-term durability in environments exposed to dust or incidental moisture.

The 1FK7061-4CF71-1BG0 motor features a high-resolution 24-bit single-turn absolute encoder with DRIVE-CLiQ interface (AS24DQI), enabling accurate position and speed feedback for advanced motion control architectures. Its plain shaft with tolerance class N ensures stable mechanical performance, while the absence of a holding brake simplifies installation for systems that do not require static torque. This configuration fits seamlessly into automation platforms needing a dependable drive component that can operate continuously with minimal maintenance. The blend of power density, structural integrity, and encoder precision makes it suitable for industrial operations where consistent accuracy and robust control are required.

Overview

SIMOTICS S-1FK7 motors are compact permanent-magnet synchronous motors designed to meet the evolving demands of modern automated machinery. Their wide range of configurations, including multiple encoder options and available gear units, allows them to be tailored for diverse applications. When paired with SINAMICS S120 or S220 drive systems, they form an efficient and responsive solution for motion control tasks. These motors are optimized for convection cooling, with heat dissipation occurring through their external surfaces, ensuring stable operation under continuous loads.

• High overload capability
• Flexible adaptation to various drive systems
• Multiple speed and control options via encoder selection

Benefits

• Compact design with excellent power density for space-critical installations
• Wide application compatibility due to extensive modular options
• High Dynamic versions offer superior dynamic response
• High Inertia versions provide stable closed-loop behavior for fluctuating loads
• Reduced commissioning time with optimized inertia matching and disturbance compensation

Application

• Machine tools and precision automation
• Robotics and handling equipment
• Wood, glass, stone, and ceramic processing
• Packaging, plastics, and textile machines
• Printing machines and auxiliary motion axes

Download

Data Sheet (PDF)

Product Code: 1FK7061-4CF71-1BG0 —
View Siemens Product Page
