1FK7061-4CF71-1CG0 SIEMENS Exclusive SIMOTICS S Motor Original Brand New
$2,111.87
The SIEMENS 1FK7061-4CF71-1CG0 is a compact, high-dynamic synchronous motor offering precise motion control, DRIVE-CLiQ encoder technology, and durable IP64 construction.
1FK7061-4CF71-1CG0 SIEMENS Exclusive SIMOTICS S Motor Original Brand New
The SIEMENS 1FK7061-4CF71-1CG0 is a high-precision synchronous motor engineered for advanced automation and modern industrial performance. As part of the SIMOTICS S-1FK7 High Dynamic series, this motor delivers efficient torque, stable acceleration, and outstanding reliability across demanding applications. With a power rating of 1.7 kW, nominal speed of 3000 rpm, and continuous torque of 6.4 Nm, it provides consistent output even under challenging load conditions. Its plain shaft configuration, naturally cooled frame design, and IP64 protection ensure long-term durability and suitable operation in various environments without requiring external cooling equipment.
Equipped with an advanced 24-bit + 12-bit multiturn absolute encoder featuring DRIVE-CLiQ connectivity, the motor supports accurate speed and position feedback for applications requiring precise coordination. This eliminates the need for additional alignment tools while allowing seamless integration with SINAMICS S120 or S220 drive systems. The rotatable power connector further simplifies installation, making the motor adaptable for compact machinery layouts or restricted mounting spaces.
The SIMOTICS S-1FK7 1FK7061-4CF71-1CG0 motor family is known for its high power density, mechanical robustness, and compatibility across a wide selection of automation frameworks. These characteristics allow for tailored configurations with gear units, encoder variations, and different inertia classes. The High Dynamic variant of the 1FK7 motor range, such as this model, achieves exceptional response behavior due to its low rotor moment of inertia, enabling precise acceleration and optimized cycle times.
Overview
SIMOTICS S-1FK7 motors are compact permanent-magnet synchronous motors designed to meet evolving industrial requirements. They can be matched with the SINAMICS drive ecosystem to create a unified, high-performance motion platform. Depending on the specific application, various encoder systems can be selected to support accurate position and speed control. These motors operate without external fans, dissipating heat across the motor housing for reliable thermal behavior. In addition, the series offers excellent overload capability, enhancing performance in dynamic operating cycles.
- Space-saving installation due to high power density
- Flexible configuration across a wide range of motor variants
- High Dynamic motors deliver exceptional responsiveness
- High Inertia motors provide stable control for heavy loads
- Minimal optimization and commissioning requirements
Applications
- Machine tools and precision equipment
- Robotics and automated handling systems
- Wood, glass, stone, and ceramics processing
- Packaging, textile, and plastics machinery
- Printing machines and auxiliary axes
Download
Product Code: 1FK7061-4CF71-1CG0 —
View Siemens Product Page
More siemens products at Turll.com
| Weight | 9.501 kg |
|---|
