1FK7061-4CF71-1CH1-ZQ31 SIEMENS Exclusive SIMOTICS S-1FK7 Motor Original Brand New

1FK7061-4CF71-1CH1-ZQ31 SIEMENS Exclusive SIMOTICS S-1FK7 Motor Original Brand New

The SIEMENS 1FK7061-4CF71-1CH1-ZQ31 is a high-performance synchronous motor engineered to deliver precise motion control, stable torque output, and excellent operational efficiency for advanced automation environments. As part of the SIMOTICS S-1FK7 High Dynamic series, this motor delivers 1.7 kW rated power, a nominal speed of 3000 rpm, and a torque rating of 6.4 Nm, providing the responsiveness required in applications where accuracy and reliability are critical.

It features a durable construction with an IP65 protection class, supporting operation in demanding industrial conditions. Equipped with a 24-bit + 12-bit multiturn absolute encoder with DRIVE-CLiQ interface (AM24DQI), this model ensures precise feedback for complex coordinated motion tasks. The rotatable power connector, naturally cooled housing, and plain shaft with N-grade tolerance further enhance installation flexibility.

A factory-installed holding brake adds secure load-holding capability, improving safety and positioning stability. The motor is optimized for use with SINAMICS S120/S220 drive systems, creating a high-performance control platform capable of supporting dynamic profiles and rapid cycle demands. Its compact structure and high power density allow efficient use of installation space, making it suitable for machines requiring a blend of speed, repeatability, and long-term endurance.

Overview

SIMOTICS S-1FK7 motors are permanent-magnet synchronous motors known for their compact form, high power density, and adaptability. A wide variety of available options, encoders, and gear combinations enables precise tailoring to numerous machine concepts. These motors achieve outstanding dynamic behavior and stability when paired with SINAMICS S-series converters, making them well suited for multi-axis systems.

• Designed for operation without external cooling
• High overload capability for demanding cycles
• Selectable encoder systems for speed and position control
• Adaptable to new machine generations with increasing performance demands

Key Benefits

• Compact design for space-saving installation
• High dynamic response due to low rotor inertia
• Stable closed-loop properties for variable load conditions
• Efficient commissioning with minimal optimization effort

Applications

• Machine tools and automation equipment
• Robotics and handling systems
• Material processing machines (wood, glass, stone)
• Packaging, plastics, and textile industries
• Printing machines and auxiliary axes

Download

Data Sheet (PDF)

Product Code: 1FK7061-4CF71-1CH1-ZQ31 —
View Siemens Product Page
