1FK7061-4CF71-1PA0 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New

1FK7061-4CF71-1PA0 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New

The SIEMENS 1FK7061-4CF71-1PA0 SIMOTICS S motor is a high-performance permanent-magnet synchronous unit engineered for demanding automation applications that require accuracy, stability, and long-term reliability. This model belongs to the SIMOTICS S-1FK7 High Dynamic series, a motor family known for exceptional mechanical precision and impressive responsiveness. With a rated power of 1.7 kW, 6.4 Nm torque, and a nominal speed of 3000 rpm, it is built to support fast cycles and reliable positioning in advanced machinery. Its IP64 protection rating, naturally cooled design, and compact frame allow seamless integration even in environments where temperature stability, robustness, and compact construction are essential.

This motor features a two-pole resolver with DRIVE-CLiQ interface, enabling high-quality feedback for speed and position control. The shaft is equipped with a fitted key manufactured with tolerance class N, ensuring dependable torque transfer and smooth coupling with mechanical systems. The absence of a holding brake makes this configuration ideal for dynamic applications that emphasize motion accuracy rather than static load retention. The rotatable power connector and IMB 5 construction provide installation flexibility, while the motor surface efficiently dissipates heat without external cooling equipment.

Overview

The SIMOTICS S-1FK7 series is designed to meet the growing requirements of sophisticated machine generations. These motors combine strong performance, compact dimensions, and a broad range of variants including different gearboxes and encoder types. When combined with SINAMICS S120 or S220 drive systems, they offer a complete drive solution with smooth control characteristics and high functional safety. Their overload capability and precise feedback options support applications requiring finely tuned, repeatable motion.

• Compact permanent-magnet synchronous motors
• Wide selection of encoders, gear units, and mechanical variants
• Flexible adaptation to diverse automation systems
• Optimized for use with SINAMICS drives

Benefits

• High power density enabling space-saving machine layouts
• Suitable for a broad range of industrial uses
• High Dynamic variants offer fast response due to low inertia
• High Inertia versions provide stable control for heavy loads
• Minimal commissioning effort thanks to optimized control behavior

Application

• Machine tools and precision assemblies
• Robotics and automated handling systems
• Glass, wood, ceramics and stone processing
• Packaging, textile and plastics machinery
• Printing and auxiliary industrial axes

Download

Data Sheet (PDF)

Product Code: 1FK7061-4CF71-1PA0 —
