1FK7061-4CF71-1QA1 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New

1FK7061-4CF71-1QA1 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New

The SIEMENS 1FK7061-4CF71-1QA1 SIMOTICS S motor is engineered for applications that require precision, durability, and smooth performance in demanding automation environments. With a rated power of 1.7 kW, a 600 V DC link voltage, and a continuous torque capability of 6.4 Nm, this motor delivers stable operation even under variable load conditions. Designed with natural cooling, the motor efficiently dissipates heat through its external surfaces, making it suitable for operation without supplemental cooling components. Its IMB 5 mounting design supports multiple installation orientations, ensuring compatibility with a wide variety of modern industrial machines. The unit is equipped with a rotatable power connector and a high-resolution single-turn absolute encoder with DRIVE-CLIQ interface for reliable speed and position tracking.

The rugged construction of the SIMOTICS S motor, including its IP65 protection rating, supports operation in environments where dust, oil mist, and moisture may be present. The shaft is fitted with a precision key for stable torque transmission, and the encoder technology enables precise feedback in closed-loop systems. This configuration offers both mechanical robustness and exceptional accuracy, ensuring long-term reliability in high-performance drive applications.

Overview

SIMOTICS S-1FK7 motors are compact permanent-magnet synchronous motors that combine mechanical strength with outstanding motion control capabilities. The series offers multiple encoder options, diverse flange configurations, and compatibility with SINAMICS S120 and S220 drive systems. These motors are tailored for performance-critical operations that require responsive motion, stable control characteristics, and high overload capacity. By utilizing integrated encoder systems, users can match the motor precisely to the control requirements of each machine.

Benefits

• Compact structure with high power density for space-limited installations
• Adaptable for universal use across numerous machinery types
• High Dynamic variants with superior acceleration behavior
• High Inertia variants for stable control with fluctuating loads
• Reduced commissioning effort due to advanced feedback systems

Application

• Machine tools
• Robotics and automated handling systems
• Processing equipment for wood, glass, stone, and ceramics
• Packaging, plastics, and textile machinery
• Printing and auxiliary machine axes

Download

Data Sheet (PDF)

Product Code: 1FK7061-4CF71-1QA1 —
View Siemens Product Page
