1FK7061-4CF71-1RA2 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New

1FK7061-4CF71-1RA2 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New

The SIEMENS 1FK7061-4CF71-1RA2 is a high-performance synchronous motor engineered for demanding motion control environments where precision, stability, and long-term reliability are essential. As part of the SIMOTICS S 1FK7 High Dynamic series, this motor offers an excellent balance of power, responsiveness, and mechanical robustness. It delivers a rated power of 1.7 kW and a stall torque of 6.4 Nm, making it suitable for diverse machine-builder requirements. The naturally cooled design ensures consistent heat dissipation, enabling dependable performance even in intensive continuous-operation applications. Designed with IMB5 mounting, a rotatable power connector, and a DRIVE-CLiQ absolute encoder system, this model supports streamlined installation and advanced motion feedback, enhancing its suitability for precise automation setups.

This motor is equipped with a 20-bit plus 12-bit multiturn encoder, allowing highly accurate speed and position data transmission. Its rugged mechanical structure includes an IP65 motor housing and IP67 flange, providing strong environmental protection. With a shaft featuring a fitted key and tolerance class N, the device allows stable mechanical coupling in a wide range of motion-control tasks. This configuration is built without a holding brake, reducing mechanical complexity while maintaining smooth dynamic behavior.

Overview

SIMOTICS S-1FK7 motors are compact synchronous units designed to deliver consistent torque, highly dynamic performance, and flexible configuration options. They pair seamlessly with SINAMICS S120 and S220 drive systems to form efficient, integrated automation solutions. The series supports multiple encoder systems and offers wide adaptability for different machine designs. These motors dissipate heat through their external surface, enabling operation without additional cooling devices. Their high overload capability and modular expansion options make them suitable for modern automation architectures.

Benefits

• High power density enabling compact installation
• Flexible selection options for universal applications
• Wide motor portfolio for tailored system design
• High dynamic response with low rotor inertia
• Stable control behavior for varying load conditions
• Reduced commissioning effort due to optimized control performance

Application

• Machine tools and precision manufacturing systems
• Robotic arms and automated handling equipment
• Wood, glass, ceramic, and stone processing machines
• Packaging, plastic, and textile machinery
• Industrial printing equipment
• Auxiliary axes in modular automation systems

Download

Data Sheet (PDF)

Product Code: 1FK7061-4CF71-1RA2 —
View Siemens Product Page
